System And Components
222-1449 ADAPTER GP-FAST FILL FUELS/N RJG1388-3999
Group No: 222-1449
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4J8820 | 1 SPACER (1.25X2X1.5-IN THK) | 2 | |
| 6Y0091 | 2 BLOCK AS | 1 | |
| 9D0630 | 3 CAP-DUST | 1 | |
| 1242463 | 4 ADAPTER-FAST FILL FUEL | 1 | |
| 1274978 | 5 HOSE AS | 1 | |
| 1420406 | 6 BRACKET AS | 1 | |
| 2525806 | 7 VALVE AS-SHUTOFF (FAST FILL FUEL) | 1 | |
| 2525805 | 8 VENT AS | 1 | |
| 1740050 | 9 HOSE AS | 1 | |
| 3E6773 | 10 SEAL-O-RING | 1 | |
| 1J9671 | 11 SEAL-O-RING | 2 | |
| 1P4582 | 12 FLANGE-HALF | 4 | |
| 4J0527 | 13 SEAL-O-RING | 2 | |
| 9X7287 | 14 SEAL-O-RING | 1 | |
| 5P2566 | 15 BOLT (1/2-13X1.5-IN) | 4 | |
| 5P2618 | 16 CONNECTOR | 2 | |
| 6V2686 | 17 CLIP | 1 | |
| 7X0340 | 19 BOLT (1/2-13X6.5-IN) | 2 | |
| 8C8844 | 20 BOLT (1-8X5-IN) | 2 | |
| 1053484 | 21 BOLT-SOCKET HEAD (M10X1.5X25-MM) | 6 | |
| 8T4133 | 22 NUT (M10X1.5-THD) | 1 | |
| 8T4136 | 23 BOLT (M10X1.5X25-MM) | 7 | |
| 8T4223 | 24 WASHER-HARD (13.5X25.5X3-MM THK) | 10 | |
| 8T5361 | 25 WASHER-HARD (28X49X5-MM THK) | 2 | |
| 8T4184 | 26 BOLT (M12X1.75X45-MM) | 4 | |
| 8T4121 | 27 WASHER-HARD (11X21X2.5-MM THK) | 14 |
