System And Components
268-0775 LINES GP-STEERING CYLINDERS/N CXM1-UP
Group No: 268-0775
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2117371 | 1 HOSE AS | 2 | |
| 7G3833 | 2 CLIP (TAB) | 1 | |
| 7G3834 | 3 CLIP (SLOT) | 1 | |
| 5V5734 | 4 MANIFOLD | 2 | |
| 8T4195 | 5 BOLT (M10X1.5X30-MM) | 8 | |
| 8T4121 | 6 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 1P4579 | 7 FLANGE-HALF | 4 | |
| 8T8919 | 8 BOLT (1/2-13X1.75-IN) | 8 | |
| 8T4223 | 9 WASHER-HARD (13.5X25.5X3-MM THK) | 10 | |
| 4J0524 | 10 SEAL-O-RING | 2 | |
| 1P4578 | 11 FLANGE-HALF | 12 | |
| 8T8916 | 12 BOLT (7/16-14X1.5-IN) | 24 | |
| 8T5360 | 13 WASHER (12X22.5X2.5-MM THK) | 24 | |
| 4J0522 | 14 SEAL-O-RING | 6 | |
| 6V9007 | 15 ELBOW | 4 | |
| 3D2824 | 16 SEAL-O-RING | 4 | |
| 5P1075 | 17 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 2680777 | 18 HOSE AS | 2 | |
| 7G3832 | 19 GROMMET | 1 | |
| 8T2502 | 20 BOLT (3/8-16X1.125-IN) | 2 | |
| 2680776 | 21 HOSE AS | 2 | |
| 2063930 | 22 VALVE & MTG GP-STEERING | 1 | |
| 2117376 | 23 BRACKET AS | 1 | |
| 6V8801 | NUT (3/8-16-THD) | 2 | |
| 8T9377 | 25 BOLT (3/8-16X2.25-IN) | 2 | |
| 8T4896 | 26 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 6V9746 | 27 SEAL-O-RING | 4 | |
| 8T4192 | 28 BOLT (M12X1.75X25-MM) | 2 | |
| 8S0023 | 29 CLIP (SLOT) | 2 | |
| 8S0024 | 30 CLIP (TAB) | 2 |
