System And Components
8J-6099 VALVE GP-DIVERTERS/N CXM1-539
Group No: 8J-6099
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5J9101 | 1 SHIM (0.25-MM THK) | 12 | |
| 8J6782 | 2 COVER | 1 | |
| 0682121 | 3 BOLT (1/2-13X2.36-IN) | 4 | |
| 1J9533 | 4 SPRING | 2 | |
| 8T9391 | 5 BOLT (1/2-13X3.75-IN) | 1 | |
| 8T4223 | 6 WASHER-HARD (13.5X25.5X3-MM THK) | 20 | |
| 8T8919 | 7 BOLT (1/2-13X1.75-IN) | 7 | |
| 4J8997 | 8 SEAL-O-RING | 1 | |
| 8J6784 | 9 COVER | 1 | |
| 3S3433 | 10 SLEEVE-SPLIT | 4 | |
| 8J6785 | 11 SPRING | 1 | |
| 4J0528 | 12 SEAL-O-RING | 1 | |
| 4J0525 | 13 SEAL-O-RING | 3 | |
| 4J0524 | 16 SEAL-O-RING | 4 | |
| 1P4579 | 18 FLANGE-HALF | 6 | |
| 5P2566 | 19 BOLT (1/2-13X1.5-IN) | 8 | |
| 1J8945 | 20 VALVE | 2 | |
| 8J6787 | 21 ORIFICE | 1 | |
| 1837262 | 22 PLUG AS | 2 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 9S8010 | PLUG | 1 | |
| 1733993 | 23 PLUG AS | 3 | |
| 4J7533 | SEAL-O-RING | 1 | |
| 9S8001 | PLUG (5/16-24-THD) | 1 | |
| 5J3419 | 24 SPRING | 1 | |
| 3G7628 | 26 SPACER | 1 |
