System And Components
8J-2318 VALVE GP-STEERINGS/N CXM1-UP
Group No: 8J-2318
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4F7115 | 1 SPRING | 1 | |
| 4T0317 | 2 SEAT | 1 | |
| 4T0318 | 3 SEAT | 1 | |
| 7M8538 | 5 SPACER (0.9-MM THK) | 3 | |
| 8B3115 | 6 SHIM (0.25-MM THK) | 3 | |
| 8J2634 | 8 SPRING (INNER) | 1 | |
| 8J2635 | 9 SPRING (OUTER) | 1 | |
| 8J3659 | 11 STOP AS | 1 | |
| 8J3660 | 12 RETAINER | 1 | |
| 8J3661 | 13 RETAINER | 1 | |
| 8J3662 | 14 SPACER (4.8-MM THK) | 1 | |
| 8J3664 | 15 COVER | 1 | |
| 8J3665 | 16 COVER | 1 | |
| 8M8211 | 19 SPACER (0.25-MM THK) | 1 | |
| 9H2367 | 20 SPRING-VALVE | 1 | |
| 9J4071 | 21 SPRING | 1 | |
| 9J8225 | 22 VALVE GP-RELIEF (PUMP BACKUP) | 1 | |
| 9S6154 | 23 PLUG AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9T7202 | 24 RETAINER AS | 1 | |
| 9X6395 | 25 NUT (3/4-16-THD) | 1 | |
| 1331480 | 26 SPACER (15-MM THK) | 1 | |
| 1488409 | 27 PLUG AS | 1 | |
| 9S8008 | PLUG (1-1/16-12-THD) | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 1488411 | 28 PLUG AS | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 1733993 | 29 PLUG AS | 8 | |
| 9S8001 | PLUG (5/16-24-THD) | 1 | |
| 4J7533 | SEAL-O-RING | 1 | |
| 1J9671 | 30 SEAL-O-RING | 1 | |
| 1P4579 | 31 FLANGE-HALF | 6 | |
| 2S4078 | 32 SEAL-O-RING | 1 | |
| 3B4508 | 33 LOCKWASHER | 1 | |
| 3J1907 | 34 SEAL-O-RING | 2 | |
| 3K0360 | 35 SEAL-O-RING | 1 | |
| 4B4280 | 36 WASHER (13.5X27X2.5-MM THK) | 1 | |
| 4B9782 | 37 BALL | 2 | |
| 4J0524 | 38 SEAL-O-RING | 1 | |
| 4J0526 | 39 SEAL-O-RING | 1 | |
| 4J0528 | 40 SEAL-O-RING | 2 | |
| 4J5309 | 41 SEAL-O-RING | 4 | |
| 5S2389 | 42 BOLT-SOCKET HEAD (1/2-13X2.75-IN) | 1 | |
| 8T4223 | 43 WASHER-HARD (13.5X25.5X3-MM THK) | 21 | |
| 8T4835 | 44 BOLT (1/2-13X2-IN) | 3 | |
| 8T8919 | 45 BOLT (1/2-13X1.75-IN) | 12 | |
| 8T9391 | 46 BOLT (1/2-13X3.75-IN) | 6 | |
| 9J9821 | 47 SEAT | 1 | |
| 9M6803 | 48 DOWEL | 1 | |
| 3549228 | 49 VALVE GP-CONTROL (STEERING) | 1 |
