System And Components
133-8612 VALVE GP-MAIN CONTROL -3-FUNCTION, LOGGINGS/N 2TW1-UP
Group No: 133-8612
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1655085 | 1 BOLT-SOCKET HEAD (M12X1.75X160-MM) | 6 | |
| 3H3385 | 2 SEAL-O-RING | 2 | |
| 6V5759 | 3 SEAL-O-RING | 2 | |
| 6V0852 | 4 CAP-DUST | 5 | |
| 8L6565 | 5 PIN-SPRING | 6 | |
| 2038482 | 6 MANIFOLD | 1 | |
| 1809550 | 7 ACTUATOR GP-PILOT CONTROL | 3 | |
| 1128244 | 8 HOUSING | 1 | |
| 1552291 | 9 HOUSING | 1 | |
| 1179341 | 10 BODY | 1 | |
| 1006731 | 11 STEM | 1 | |
| 1855626 | 12 SPRING | 1 | |
| 1438912 | 13 VALVE GP-RELIEF (PILOT OPERATED) | 1 | |
| 6E2140 | 14 RETAINER AS | 1 | |
| 7D8508 | 15 NUT-FULL (7/8-14-THD) | 1 | |
| 2M9780 | 16 SEAL-O-RING | 1 | |
| 9G4733 | 17 TUBE | 1 | |
| 9S4182 | 18 PLUG (7/16-20-THD) | 7 | |
| 9S8002 | 19 PLUG (7/16-20-THD) | 4 | |
| 8T6466 | 20 BOLT (M10X1.5X60-MM) | 3 | |
| 9R5008 | 21 SPACER (11X20X6-MM THK) | 27 | |
| 4J5309 | 22 SEAL-O-RING | 1 | |
| 8T2353 | 23 ADAPTER | 2 | |
| 3J7354 | 24 SEAL-O-RING | 13 | |
| 8T4205 | 25 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 1P3704 | 26 SEAL-RECTANGULAR | 1 | |
| 4J0523 | 27 SEAL-O-RING | 4 | |
| 0959804 | 28 BOLT-SOCKET HEAD (M12X1.75X110-MM) | 4 | |
| 1170161 | 29 VALVE GP-RELIEF (LINE, TILT CYL ROD END PORT) | 1 | |
| 1024158 | 30 PLUG AS | 3 | |
| 3G5003 | BUSHING | 1 | |
| 2S4078 | 31 SEAL-O-RING | 3 | |
| 1024156 | 32 VALVE-CONTROL | 3 | |
| 9L9188 | 33 SPRING-VALVE | 3 | |
| 1H5728 | 34 SEAL-O-RING | 3 | |
| 7J1592 | 35 COVER | 1 | |
| 9S4180 | 36 PLUG | 1 | |
| 4J7533 | 37 SEAL-O-RING | 1 | |
| 6E4286 | 38 VALVE GP-PRESSURE REDUCING | 1 | |
| 4T1860 | 39 VALVE GP-SHUTTLE (BALL RESOLVER) | 1 | |
| 9S9334 | 40 PLUG-O-RING | 3 | |
| 7M8485 | 41 SEAL-O-RING | 3 | |
| 6E1291 | 42 VALVE-CONTROL | 1 | |
| 7J7852 | 43 SPRING | 1 | |
| 1170160 | 44 VALVE GP-RELIEF (LINE, TILT CYL HEAD END PORT) | 1 | |
| 1138263 | 45 PISTON | 3 | |
| 8T4192 | 46 BOLT (M12X1.75X25-MM) | 2 | |
| 1259349 | 47 VALVE GP-RELIEF (LINE, LIFT CYL HEAD END PORT) | 1 | |
| 1P3705 | 48 SEAL-RECTANGULAR | 1 | |
| 7X2546 | 52 BOLT (M10X1.5X180-MM) | 6 | |
| 6V8397 | 53 SEAL-O-RING | 2 | |
| 9R7996 | 54 HOSE AS | 1 | |
| 6V8724 | 55 ELBOW | 1 | |
| 7X2549 | 56 BOLT (M12X1.75X100-MM) | 2 | |
| 8T5436 | 57 BOLT (M10X1.5X130-MM) | 6 | |
| 1725481 | 58 VALVE GP-RELIEF (LINE, AUX CYL ROD END PORT) | 1 | |
| 2J6274 | 59 SEAL-O-RING | 6 | |
| 6V0484 | 60 ELBOW | 2 | |
| 8T0075 | 61 CONNECTOR | 1 | |
| 9S4191 | 62 PLUG (9/16-18-THD) | 5 | |
| 9S8004 | 63 PLUG (9/16-18-THD) | 3 | |
| 6V3965 | 64 FITTING (QUICK DISCONNECT) | 5 | |
| 3J1907 | 65 SEAL-O-RING | 17 | |
| 4B4158 | 66 SCREW-DRIVE (NO 4X0.25-IN) | 6 | |
| 1798248 | 67 ACTUATOR GP-PILOT CONTROL | 3 | |
| 8T4140 | 68 BOLT (M16X2X60-MM) | 12 | |
| 8T4122 | 69 WASHER-HARD (17X32X3.5-MM THK) | 12 | |
| 5P8077 | 70 FLANGE-HALF | 6 | |
| 1170161 | 71 VALVE GP-RELIEF (LINE, LIFT CYL ROD END PORT) | 1 | |
| 1725481 | 72 VALVE GP-RELIEF (LINE, AUX CYL HEAD END PORT) | 1 | |
| 6E4287 | KIT-SEAL (PRESSURE REDUCING VALVE) | 1 |
