System And Components
212-8712 VALVE GP-MAIN CONTROL -2-FUNCTIONS/N BXY1-UP
Group No: 212-8712
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4B4158 | 1 SCREW-DRIVE (NO 4X0.25-IN) | 4 | |
| 4T1860 | 2 VALVE GP-SHUTTLE (BALL RESOLVER)(BALL RESOLVER) | 1 | |
| 6E1291 | 3 VALVE-CONTROL | 1 | |
| 7D8508 | 4 NUT-FULL (7/8-14-THD) | 1 | |
| 7X2459 | 5 ADAPTER-TEE | 1 | |
| 9G4733 | 6 TUBE | 1 | |
| 9L9188 | 7 SPRING-VALVE | 2 | |
| 9R5008 | 8 SPACER (11X20X6-MM THK) | 19 | |
| 9R7996 | 9 HOSE AS | 1 | |
| 1006731 | 10 STEM | 1 | |
| 1024156 | 11 VALVE-CONTROL | 2 | |
| 1128244 | 12 HOUSING | 1 | |
| 1138263 | 13 PISTON | 2 | |
| 1170159 | 14 VALVE GP-RELIEF (MAIN) | 1 | |
| 4237704 | 15 VALVE GP-RELIEF (TILT CYLINDER HEAD END) | 1 | |
| 1179341 | 16 BODY | 1 | |
| 4237708 | 17 VALVE GP-RELIEF (LIFT CYLINDER HEAD END) | 1 | |
| 1855626 | 20 SPRING | 1 | |
| 2038482 | 21 MANIFOLD | 1 | |
| 2176719 | 24 ACTUATOR GP-PILOT CONTROL (REGENERATION VALVE) | 2 | |
| 2176720 | 25 ACTUATOR GP-PILOT CONTROL | 2 | |
| 2224737 | 26 PLUG AS | 1 | |
| 4J7533 | SEAL-O-RING | 1 | |
| 9S4180 | PLUG | 1 | |
| 0959804 | 27 BOLT-SOCKET HEAD (M12X1.75X110-MM) | 4 | |
| 1024158 | 28 PLUG AS | 2 | |
| 3G5003 | BUSHING | 1 | |
| 4237707 | 29 VALVE GP-RELIEF (LIFT CYLINDER ROD END) | 1 | |
| 4237707 | 29A VALVE GP-RELIEF (TILT CYLINDER ROD END) | 1 | |
| 1488406 | 30 PLUG AS | 3 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 9S9334 | PLUG-O-RING | 1 | |
| 1488407 | 31 PLUG AS | 6 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 1553624 | 32 PLUG AS | 7 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 9S4182 | PLUG (7/16-20-THD) | 1 | |
| 1620177 | 33 PLUG AS | 5 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 1837263 | 34 PLUG AS | 4 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 1H5728 | 35 SEAL-O-RING | 2 | |
| 1P3705 | 36 SEAL-RECTANGULAR | 1 | |
| 2J6274 | 37 SEAL-O-RING | 4 | |
| 2M9780 | 38 SEAL-O-RING | 1 | |
| 2S4078 | 39 SEAL-O-RING | 2 | |
| 3J1907 | 40 SEAL-O-RING | 4 | |
| 3J7354 | 41 SEAL-O-RING | 2 | |
| 4J0523 | 42 SEAL-O-RING | 1 | |
| 4J0525 | 43 SEAL-O-RING | 1 | |
| 4J5309 | 44 SEAL-O-RING | 1 | |
| 6E2140 | 45 RETAINER AS | 1 | |
| 6E4286 | 46 VALVE GP-PRESSURE REDUCING | 1 | |
| 6V0852 | 47 CAP-DUST | 2 | |
| 6V3668 | 48 BOLT (M12X1.75X30-MM) | 2 | |
| 6V3965 | 49 FITTING (QUICK DISCONNECT) | 2 | |
| 6V5759 | 50 SEAL-O-RING | 2 | |
| 6V8397 | 51 SEAL-O-RING | 2 | |
| 7J7852 | 52 SPRING | 1 | |
| 7X2546 | 53 BOLT (M10X1.5X180-MM) | 4 | |
| 7X2549 | 54 BOLT (M12X1.75X100-MM) | 2 | |
| 8L6565 | 55 PIN-SPRING | 4 | |
| 8T0075 | 56 CONNECTOR | 1 | |
| 8T2353 | 57 ADAPTER | 2 | |
| 8T4139 | 58 BOLT (M12X1.75X30-MM) | 4 | |
| 8T4205 | 59 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 8T4223 | 60 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T5436 | 61 BOLT (M10X1.5X130-MM) | 4 | |
| 8T6466 | 62 BOLT (M10X1.5X60-MM) | 3 | |
| 7J1592 | 63 COVER | 1 | |
| 6E4287 | KIT-SEAL (PRESSURE REDUCING VALVE) | 1 |
