System And Components
261-8405 SHAFT GP-DRIVE -OSCILLATIONS/N CXM1-UP
Group No: 261-8405
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5K3968 | 1 RETAINER-BEARING | 1 | |
| 5K4079 | 2 CAGE-BEARING | 2 | |
| 1593945 | 3 BEARING | 1 | |
| 1767289 | 4 YOKE AS | 2 | |
| 9U3928 | GUARD | 1 | |
| 1868274 | 5 BEARING-ROLLER | 1 | |
| 2111854 | 6 SHAFT-DRIVE | 1 | |
| 2111855 | 7 CAGE-BEARING | 1 | |
| 2624223 | 8 PLATE AS | 1 | |
| 1H8278 | 9 SEAL-O-RING | 2 | |
| 2618403 | 10 CARRIER | 1 | |
| 2618404 | 11 FLANGE | 1 | |
| 2D8540 | 12 SEAL-LIP TYPE | 4 | |
| 2H3933 | 13 SEAL-O-RING | 2 | |
| 8T0360 | 14 BOLT (M20X2.5X90-MM) | 2 | |
| 8T0656 | 15 BOLT (M20X2.5X150-MM) | 9 | |
| 8T0657 | 16 BOLT (M20X2.5X160-MM) | 3 | |
| 8T3282 | 17 WASHER-HARD (22X35X3.5-MM THK) | 12 | |
| 8T4223 | 18 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 8T4896 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 8T4910 | 20 BOLT (M12X1.75X60-MM) | 12 | |
| 8V5386 | 21 RETAINER | 2 | |
| 9B7237 | 22 BOLT (3/8-16X1.25-IN) | 4 |
