System And Components
311-0065 LINES GP-HYDRAULIC FANS/N M1G1-UP
Group No: 311-0065
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P4278 | 1 CLAMP-HOSE | 1 | |
| 7K1181 | 2 STRAP-CABLE | 11 | |
| 3658417 | 3 HOSE AS | 1 | |
| 3080169 | 4 HOSE AS | 1 | |
| 3113170 | 5 PUMP GP-AIR (VARIABLE PITCH FAN) | 1 | |
| 3192140 | 6 HOSE AS | 1 | |
| 3233883 | 7 HOSE AS | 1 | |
| 3247874 | 8 HOSE AS | 1 | |
| 3074402 | 9 HOSE AS | 1 | |
| 3574427 | 10 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8627 | ELBOW | 1 | |
| 1488389 | 11 ELBOW AS | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 7X0492 | ELBOW | 1 | |
| 2965749 | 12 ELBOW AS | 1 | |
| 4J5477 | SEAL-O-RING | 2 | |
| 6V8986 | ELBOW | 1 | |
| 2P1279 | 13 LOCKNUT (9/16-18-THD) | 1 | |
| 1M4543 | 14 GROMMET | 1 | |
| 8T4133 | 15 NUT (M10X1.5-THD) | 1 | |
| 8T4136 | 16 BOLT (M10X1.5X25-MM) | 1 | |
| 5P8440 | 17 GROMMET | 1 | |
| 6K8178 | 18 CLIP (LOOP) | 1 | |
| 6V1889 | 19 CLIP (LOOP) | 2 | |
| 1837258 | 20 ELBOW AS | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 7X5331 | ELBOW | 1 | |
| 4K8864 | 21 CLIP (LOOP) | 2 | |
| 8T4121 | 22 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4137 | 23 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4195 | 24 BOLT (M10X1.5X30-MM) | 1 | |
| 8T4197 | 25 BOLT (M8X1.25X40-MM) | 3 | |
| 9M8406 | 26 CLIP (LOOP) | 1 | |
| 9N0869 | 27 WASHER-HARD (8.8X25.5X2-MM THK) | 3 | |
| 8C5064 | 28 CONDUIT-FLEXIBLE (17.75-MM ID, SPLIT)(38-CM) | ||
| 8C5064 | 28A CONDUIT-FLEXIBLE (17.75-MM ID, SPLIT)(22-CM) | ||
| 9X7381 | 29 SEAL-O-RING | 2 | |
| 1656365 | 30 FITTING AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 7W7381 | FITTING-OUTLET | 1 | |
| 7C4354 | 31 CLIP | 1 | |
| 7X0510 | 32 WASHER-HARD (15.5X29X3-MM THK) | 1 |
