System And Components
387-8457 C-FRAME GPS/N EG61-UP
Group No: 387-8457
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B8488 | 1 FITTING-GREASE (1/8-27 PTF) | 1 | |
| 1044817 | 2 PIN | 1 | |
| 1933063 | 3 CAP AS-BEARING | 2 | |
| 1956283 | 4 NUT-SQUARE (M30X3.5-THD) | 4 | |
| 2233279 | 5 RETAINER | 1 | |
| 2267191 | 6 RETAINER | 2 | |
| 2291516 | 7 SPACER (64X72X18-MM THK) | 2 | |
| 2826598 | 9 SPACER (50.8X57.15X4.73-MM THK) | 4 | |
| 2826604 | 10 PIN | 2 | |
| 2926035 | 11 PLATE-RETAINER | 1 | |
| 3139790 | 12 SPACER (50.8X57.15X35-MM THK) | 2 | |
| 3878458 | 13 C-FRAME AS | 1 | |
| 1K6985 | 13A RING-RETAINING | 4 | |
| 9M1328 | 13B BEARING-SELF-ALIGNING | 2 | |
| 2741715 | 13C STEP AS | 2 | |
| 2333642 | 13D TRUNNION AS | 1 | |
| 2826605 | 13E BEARING | 2 | |
| 4181226 | 14 PIN | 1 | |
| 4230715 | 15 PIN | 2 | |
| 3B8489 | 16 FITTING-GREASE (1/8-27 PTF) | 1 | |
| 3E9850 | 17 BOLT (M30X3.5X220-MM) | 4 | |
| 7X0515 | 18 WASHER-HARD (17X35X5-MM THK) | 3 | |
| 7X2546 | 19 BOLT (M10X1.5X180-MM) | 4 | |
| 8T0389 | 20 LOCKNUT (M10X1.5-THD) | 4 | |
| 8T4123 | 21 WASHER (22X35X3.5-MM THK) | 1 | |
| 8T6430 | 22 BOLT (M20X2.5X50-MM) | 1 | |
| 8T7338 | 23 BOLT (M16X2X45-MM) | 3 | |
| 9J4782 | 24 PROTECTOR | 2 | |
| 9X2027 | 25 WASHER (11X18X2-MM THK) | 8 | |
| 9X8258 | 26 WASHER (33X56X6-MM THK) | 4 | |
| 9W7602 | 27 SHIM (0.8-MM THK) | 52 | |
| 5147641 | 28 SPACER | 4 |
