System And Components
107-0701 WHEEL & FINAL DRIVE GPS/N KK21-UP
Group No: 107-0701
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1311296 | 1 SPINDLE | 1 | |
| 1953495 | 2 SEAL GP-DUO-CONE | 1 | |
| 5P4946 | RING-SEALING | 2 | |
| 1265859 | 3 CONE | 1 | |
| 1265860 | 4 CUP-TAPERED | 1 | |
| 1070692 | 5 WHEEL | 1 | |
| 1119177 | 6 SPACER (92.2X122.2X27.3-MM THK) | 1 | |
| 1427073 | 7 BOLT-SOCKET HEAD | 4 | |
| 8T8917 | 8 BOLT (1/2-13X1.25-IN) | 9 | |
| 8T4223 | 9 WASHER-HARD (13.5X25.5X3-MM THK) | 9 | |
| 6W1140 | 10 WASHER-THRUST | 6 | |
| 1279504 | 11 GEAR-PLANETARY (34-TEETH) | 3 | |
| 1070695 | 12 SHIM PACK (INCLUDES 16-SHIMS) | 1 | |
| 1628304 | 13 GEAR-SUN (15-TEETH) | 1 | |
| 1916265 | 14 BOLT (3/4-10X3.25-IN) | 20 | |
| 1122165 | 15 COVER AS | 1 | |
| 1U8846 | SEALANT-GASKET | ||
| 8T4896 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 0343557 | BOLT-LOCKING (3/8-16X1.125-IN) | 4 | |
| 1070704 | PLATE | 1 | |
| 9H6832 | 16 SEAL-O-RING | 1 | |
| 4684053 | 17 CARRIER-PLANETARY | 1 | |
| 1111503 | 18 SEAL-O-RING | 1 | |
| 5K7696 | 19 PLUG | 1 | |
| 3J1907 | 20 SEAL-O-RING | 1 | |
| 1070689 | 21 GEAR-RING (87-TEETH) | 1 | |
| 1070691 | 22 HUB | 1 | |
| 1117759 | 23 RETAINER | 1 | |
| 1110897 | 24 CONE-BEARING | 1 | |
| 1110898 | 25 CUP-BEARING | 1 | |
| 1070698 | 26 RING-RETAINING | 1 | |
| 0344160 | 27 BOLT-LOCKING (5/16-18X1-IN) | 6 | |
| 8E9571 | 28 WASHER-HARD (8.8X16X7-MM THK) | 6 | |
| 1081554 | 29 BUSHING | 3 | |
| 9Y2596 | 30 DOWEL | 3 | |
| 4684042 | 31 SHAFT | 3 | |
| 6V0439 | 32 PLUG-MAGNETIC | 1 | |
| 2S4078 | 33 SEAL-O-RING | 1 | |
| 1V6659 | 34 RING-RETAINING | 1 | |
| 6V1746 | 35 DOWEL | 2 |
