System And Components
152-2131 AXLE GP-OSCILLATING -REARPART OF 152-5276 AXLE AR-OSCILLATING
Group No: 152-2131
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1D4608 | 1 BOLT (3/4-10X2.75-IN) | 16 | |
| 2V2755 | 2 PLATE-THRUST | 1 | |
| 2V2757 | 3 COVER | 1 | |
| 2V2761 | 4 RETAINER-BEARING | 1 | |
| 4E0078 | 5 TRUNNION | 1 | |
| 4E0083 | 6 HOUSING-AXLE | 1 | |
| 4E3095 | 7 SUPPORT-TRUNNION | 1 | |
| 4E3096 | 8 SUPPORT-TRUNNION | 1 | |
| 4E3108 | 9 BUSHING | 1 | |
| 4V4887 | 10 BUSHING | 1 | |
| 1516302 | 11 SHAFT-AXLE | 2 | |
| 1654929 | 12 PLUG AS-MAGNETIC | 1 | |
| 5P4484 | PLUG-MAGNETIC | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1644180 | 13 PLUG AS | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 9S4181 | PLUG-O-RING | 1 | |
| 1A1460 | 14 BOLT (1/2-13X2-IN) | 12 | |
| 1D4626 | 15 BOLT (7/8-9X2.75-IN) | 16 | |
| 1D4646 | 16 BOLT (1-8X9-IN) | 60 | |
| 1K6853 | 17 FITTING-GREASE | 2 | |
| 2K9062 | 18 PIN-SPRING | 1 | |
| 2M0849 | 19 WASHER-HARD (13.5X25.5X5-MM THK) | 12 | |
| 2S0115 | 20 WASHER-HARD (20X36.5X5-MM THK) | 28 | |
| 3B2968 | 21 BOLT (3/4-10X3.5-IN) | 12 | |
| 4V4884 | 22 SEAL-O-RING | 3 | |
| 4V4885 | 23 BEARING-THRUST | 2 | |
| 5P2861 | 24 SEAL-O-RING | 1 | |
| 6M1622 | 25 DOWEL | 4 | |
| 8T0336 | 26 FITTING-PRESSURE RELIEF | 1 | |
| 9H1031 | 27 WASHER-HARD (24X41.5X6-MM THK) | 16 | |
| 9M2828 | 28 WASHER-HARD (28X44.5X6-MM THK) | 68 | |
| 9X8896 | 29 BOLT (1-8X4-IN) | 8 | |
| 6V6640 | SEALANT |
