System And Components
112-0874 BRAKE GP-SERVICEPART OF 152-3016 WHEEL & FINAL DRIVE GP
Group No: 112-0874
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5H3701 | 1 SCREW-PURGE | 1 | |
| 8V3609 | 2 SPRING-RETRACTOR | 6 | |
| 7V8346 | 3 SPRING-GUIDE | 6 | |
| 6M9155 | 4 PIN | 6 | |
| 9S8005 | 5 PLUG-O-RING | 4 | |
| 3K0360 | 6 SEAL-O-RING | 4 | |
| 9U1734 | 7 PISTON | 1 | |
| 1326532 | 8 HUB | 1 | |
| 9U1741 | 9 RING-RETAINING | 1 | |
| 1311295 | 10 ANCHOR-BRAKE | 1 | |
| 1155658 | 11 SEAL | 1 | |
| 5M6200 | 12 SEAL-O-RING | 1 | |
| 9M5892 | 13 SEAL-O-RING | 1 | |
| 9U1742 | 14 SEAL-O-RING | 1 | |
| 2200190 | 15 DISC-FRICTION (EXTENDED LIFE) | 4 | |
| 9U1739 | 16 PLATE-OUTER | 5 | |
| 1047006 | 17 DOWEL-HOLLOW | 8 | |
| 1330992 | 18 WASHER-THRUST (109X184.4X5.72-MM THK) | 1 | |
| 8C7562 | 19 SCREW-FLAT HEAD (M8X1.25X20-MM) | 4 |
