System And Components
199-3445 CONTROL GP-PILOT OPERATED HYD -2-FUNCTIONS/N RTB1-UP
Group No: 199-3445
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4E1062 | 1 CUSHION AS-ARMREST | 1 | |
| 8T8737 | 2 PLUG-SEAL | 4 | |
| 9R1948 | 3 RIVET | 2 | |
| 1076050 | 4 SUPPORT AS | 1 | |
| 1117875 | 5 PLATE | 1 | |
| 1143940 | 7 ROD | 1 | |
| 1872082 | 8 LEVER-CONTROL | 1 | |
| 1244401 | 9 KNOB | 1 | |
| 1419188 | 10 FILM-INSTRUCTION (HYDRAULIC LOCKOUT) | 1 | |
| 1419191 | 11 PLATE-INSTRUCTION (BUCKET CONTROL) | 1 | |
| 1469047 | 12 HOSE AS | 1 | |
| 1489562 | 13 CONTROL GP-HANDLE (TILT TO TIP FUNCTION) | 1 | |
| 1548595 | 14 VALVE GP-SHUTOFF (HYDRAULIC LOCKOUT) | 1 | |
| 1593777 | 15 SUPPORT AS | 1 | |
| 1634414 | 16 COVER | 1 | |
| 2403245 | 17 VALVE GP-PILOT (2-FUNCTION) | 1 | |
| 1644885 | 18 COVER AS | 1 | |
| 1871878 | 19 WASHER-PLASTIC (8.1X19X3.2-MM THK) | 1 | |
| 1960109 | 20 ROD | 1 | |
| 1032006 | 21 SCREW-PAN HEAD (6-19X0.37-IN) | 4 | |
| 1501293 | 22 SCREW-BUTTON HEAD (M4X0.7X12-MM) | 2 | |
| 1028805 | 23 KIT-RECEPTACLE (6-PIN) | 1 | |
| 3E3383 | 24 WEDGE-RECEPTACLE LOCK (6-PIN) | 1 | |
| 3J1907 | 25 SEAL-O-RING | 3 | |
| 5C7261 | 26 NUT (M8X1.25-THD) | 4 | |
| 6V8397 | 27 SEAL-O-RING | 2 | |
| 6V8636 | 28 CONNECTOR | 1 | |
| 6V8724 | 29 ELBOW | 1 | |
| 8T4121 | 30 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4137 | 31 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4138 | 32 BOLT (M6X1X20-MM) | 2 | |
| 8T4205 | 33 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 8T4224 | 34 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T4244 | 35 NUT (M12X1.75-THD) | 2 | |
| 9X2041 | 36 SCREW-TRUSS HEAD (M10X1.5X20-MM) | 2 | |
| 9X2042 | 37 SCREW-TRUSS HEAD (M6X1X12-MM) | 6 | |
| 9X2045 | 38 SCREW-TRUSS HEAD (M6X1X20-MM) | 2 | |
| 5P5639 | 39 SEAL (1.8-M) |
