System And Components
361-4065 LINES GP-SERVICE BRAKES/N H9K1-UP
Group No: 361-4065
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1F1609 | 1 SPACER (13.5X25.4X39.7-MM THK) | 4 | |
| 6V0852 | 2 CAP-DUST | 1 | |
| 1152516 | 3 BLOCK | 2 | |
| 1646874 | 4 FITTING AS-ELBOW (QUICK DISCONNECT, MALE) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 0857356 | FITTING | 1 | |
| 2416208 | 5 ELBOW AS | 1 | |
| 2M9780 | SEAL-O-RING | 2 | |
| 5K9090 | SEAL-O-RING | 2 | |
| 1196220 | ELBOW | 2 | |
| 2757769 | 6 HOSE AS | 1 | |
| 3478704 | 7 BRACKET AS | 1 | |
| 3614070 | 8 TUBE AS | 1 | |
| 3614071 | 9 TUBE AS | 1 | |
| 3614072 | 10 TUBE AS | 1 | |
| 3614073 | 11 TUBE AS | 1 | |
| 3614076 | 12 GUARD AS (RH) | 1 | |
| 3614077 | 13 GUARD AS (LH) | 1 | |
| 1488315 | 14 CONNECTOR AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8642 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488318 | 15 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8634 | CONNECTOR | 1 | |
| 1488324 | 16 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 6V9874 | CONNECTOR | 1 | |
| 1488352 | 17 ELBOW AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9854 | ELBOW (SWIVEL) | 1 | |
| 1488388 | 18 ELBOW AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8629 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488392 | 19 ELBOW AS | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 6V9853 | ELBOW | 1 | |
| 1488407 | 20 PLUG AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 1504048 | 21 ELBOW AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8722 | ELBOW | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1645567 | 22 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1697394 | 23 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 8C3370 | CONNECTOR | 1 | |
| 4B9302 | 24 CLIP (LOOP) | 2 | |
| 5K9660 | 25 CLIP (LOOP) | 1 | |
| 5P1076 | 26 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 6D4244 | 27 CLIP (LOOP) | 1 | |
| 7X7729 | 28 WASHER (11X25X3-MM THK) | 2 | |
| 8C3206 | 29 FLANGE-HALF | 4 | |
| 8T4121 | 30 WASHER-HARD (11X21X2.5-MM THK) | 14 | |
| 8T4136 | 31 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4196 | 32 BOLT (M10X1.5X35-MM) | 8 | |
| 8T4648 | 33 BOLT (M12X1.75X70-MM) | 4 | |
| 8T6466 | 34 BOLT (M10X1.5X60-MM) | 4 |
