System And Components
398-5510 TRIM GP-CAB -LINERPART OF 515-6034 CAB AR-ENCLOSED ROPS, 515-6042 CANOPY AR
Group No: 398-5510
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9U8263 | 1 COVER | 1 | |
| 4157813 | 2 COVER (LH) | 1 | |
| 4217021 | 3 COVER-COLUMN | 1 | |
| 4217024 | 4 COVER (RH) | 1 | |
| 5087563 | 5 COVER (RH) | 1 | |
| 4257005 | 6 COVER (LH) | 1 | |
| 4257008 | 7 COVER | 1 | |
| 4305528 | 11 PLATE | 1 | |
| 4352694 | 14 FASTENER | 22 | |
| 4372519 | 15 KNOB | 3 | |
| 4372520 | 16 RETAINER | 3 | |
| 4372521 | 17 RECEPTACLE | 3 | |
| 5087561 | 19 DUCT | 2 | |
| 5585986 | 20 SEAL | 2 | |
| 4469958 | 21 PLATE | 1 | |
| 4470044 | 22 BRACKET | 1 | |
| 1282135 | 23 SCREW-TRUSS HEAD (M6X1X13-MM) | 7 | |
| 5C9553 | 25 BOLT (M6X1X16-MM) | 2 | |
| 8T4171 | 26 BOLT (M6X1X12-MM) | 2 | |
| 9X8256 | 28 WASHER (6.6X12X2-MM THK) | 4 | |
| 8T6936 | 29 SEAL (0.2-M EACH) | ||
| 8T6936 | 29A SEAL (0.1-M EACH) | ||
| 9X2044 | 30 SCREW-TRUSS HEAD (M6X1X16-MM) | 12 |
