System And Components
140-6426 LINES GP-PILOTS/N 6ZS1-1472
Group No: 140-6426
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P4278 | 1 CLAMP-HOSE | 2 | |
| 3S2093 | 2 STRAP-CABLE | 1 | |
| 5I4376 | 3 FITTING | 1 | |
| 6V0852 | 4 CAP-DUST | 1 | |
| 6V7726 | 5 SCREW-HEX SOCKET (M10X1.5X25-MM) | 2 | |
| 1409134 | 6 HOSE AS | 1 | |
| 1409135 | 7 HOSE AS | 1 | |
| 1409138 | 8 HOSE AS | 1 | |
| 1409142 | 9 HOSE AS | 2 | |
| 1409143 | 10 HOSE AS | 1 | |
| 1409144 | 11 HOSE AS | 1 | |
| 1409145 | 12 HOSE AS | 1 | |
| 1409146 | 13 HOSE AS | 1 | |
| 1409147 | 14 HOSE AS | 1 | |
| 1495532 | 15 ACCUMULATOR GP-HYDRAULIC (UNCHARGED) | 1 | |
| 5P3779 | TAG-NOTICE (SHIPPING INSTRUCTIONS) | ||
| 1542488 | 16 VALVE & MTG GP-PILOT | 1 | |
| 1553973 | 17 HOSE AS | 1 | |
| 1559966 | 18 PLATE | 1 | |
| 1559976 | 19 PLATE | 1 | |
| 1645562 | 20 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 5P1046 | CONNECTOR | 1 | |
| 1645567 | 21 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1647474 | 22 VALVE GP-CHECK | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 9T3096 | VALVE GP-CHECK | 1 | |
| 1649639 | 23 CONNECTOR AS | 4 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 1487925 | CONNECTOR | 1 | |
| 1649640 | 24 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 1452237 | CONNECTOR | 1 | |
| 1657014 | 25 TEE AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 8C3309 | TEE | 1 | |
| 0338248 | 26 CLIP (LOOP) | 3 | |
| 1043173 | 27 CLIP (LOOP) | 2 | |
| 1488325 | 28 CONNECTOR AS | 10 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8641 | CONNECTOR | 1 | |
| 1488336 | 29 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488368 | 30 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8627 | ELBOW | 1 | |
| 1488378 | 31 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1488439 | 32 TEE AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8774 | TEE | 1 | |
| 1505968 | 33 TEE AS | 1 | |
| 4J5477 | SEAL-O-RING | 2 | |
| 6V9835 | TEE | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 4D7735 | 34 CLIP | 1 | |
| 4P8134 | 35 CLIP (LADDER) | 1 | |
| 5C7261 | 36 NUT (M8X1.25-THD) | 2 | |
| 8T4121 | 37 WASHER-HARD (11X21X2.5-MM THK) | 7 | |
| 8T4133 | 38 NUT (M10X1.5-THD) | 1 | |
| 8T4136 | 39 BOLT (M10X1.5X25-MM) | 3 | |
| 8T4137 | 40 BOLT (M10X1.5X20-MM) | 3 | |
| 8T4186 | 41 BOLT (M10X1.5X40-MM) | 1 | |
| 8T4224 | 42 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T4908 | 43 BOLT (M8X1.25X25-MM) | 2 | |
| 5P1442 | 44 HOSE (68CM) |
