System And Components
337-7037 DOOR GP-CAB -LHS/N SJM324-UP
Group No: 337-7037
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1977499 | 1 BOLT (M4X0.7X25-MM) | 4 | |
| 2521862 | 2 HANDLE AS-PULL | 1 | |
| 2521863 | 3 GASKET | 1 | |
| 2531817 | 4 SPACER (6.5X14.5X12-MM THK) | 1 | |
| 2736170 | 5 GLASS (DOOR, LH) | 1 | |
| 2736182 | 6 GROMMET | 1 | |
| 5055609 | 7 SEAL-DOOR | 1 | |
| 2736191 | 8 GASKET | 1 | |
| 2843887 | 9 WASHER (7X20X1.8-MM THK) | 1 | |
| 2924754 | 10 KNOB | 1 | |
| 3033003 | 11 WINDOW-SLIDING (LH) | 1 | |
| 3081192 | 12 SPACER (6.5X14X5.8-MM THK) | 1 | |
| 3081193 | 13 SPACER | 1 | |
| 3097530 | 14 LATCH AS-DOOR (LH) | 1 | |
| 4522677 | GASKET | 1 | |
| 4522678 | PLATE | 1 | |
| 4811013 | KNOB | 1 | |
| 4811018 | LATCH AS-DOOR | 1 | |
| 3113642 | 15 COVER | 1 | |
| 3370176 | 16 LOCK-DOOR (LH) | 1 | |
| 3377047 | 17 DOOR AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 2 | |
| 3380811 | 18 COVER-LOCK (LH) | 1 | |
| 1186503 | 19 BOLT (M6X1X55-MM) | 1 | |
| 1272170 | 20 SCREW-TRUSS HEAD (M8X1.25X20-MM) | 4 | |
| 3E4352 | 21 WASHER-HARD (8.8X20.5X2.5-MM THK) | 4 | |
| 6V7357 | 22 BOLT (M6X1X25-MM) | 3 | |
| 8T0328 | 23 WASHER-HARD (5.5X10X1-MM THK) | 4 | |
| 9X2045 | 24 SCREW-TRUSS HEAD (M6X1X20-MM) | 10 | |
| 9X8256 | 25 WASHER (6.6X12X2-MM THK) | 3 | |
| 5076134 | 26 PLATE | 2 |
