System And Components
162-7859 PLANETARY GP-FINAL DRIVES/N TAR1-UP
Group No: 162-7859
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2S0480 | 1 CUP-TAPERED ROLLER | 2 | |
| 8C7505 | 2 SCREW-FLAT HEAD (M8X1.25X20-MM) | 2 | |
| 1526144 | 3 PLUG AS-DRAIN (MAGNETIC) | 1 | |
| 6V6228 | SEAL-O-RING | 1 | |
| 1570740 | 4 SEAL-LIP TYPE | 1 | |
| 1597400 | 5 STUD | 10 | |
| 1657068 | 6 PISTON-BRAKE | 1 | |
| 1657070 | 7 KIT-BRAKE | 1 | |
| 1658855 | 8 BUSHING | 8 | |
| 1670013 | 9 SEAL-BRAKE | 1 | |
| 1670014 | 10 SEAL-BRAKE | 1 | |
| 1687998 | 11 PIN | 3 | |
| 1691637 | 12 BOLT (M14X1.5X65-MM) | 8 | |
| 1788608 | 13 CONE-TAPERED | 2 | |
| 2087786 | 14 RING-LOCK | 1 | |
| 2087788 | 15 GEAR-CROWN (77-TEETH) | 1 | |
| 2087791 | 16 WASHER-THRUST (11X60X3-MM THK) | 3 | |
| 2087823 | 17 GEAR-SUN (31-TEETH) | 3 | |
| 2087862 | 18 SHAFT | 1 | |
| 2087919 | 19 BUSHING | 1 | |
| 3886412 | 20 BOLT (M10X1.25X50-MM) | 3 | |
| 3318522 | 21 BEARING AS-NEEDLE | 9 | |
| 2198783 | 22 KIT-ROLLER BEARING | 1 | |
| 2158056 | 23 WASHER-THRUST (11X60X3-MM THK) | 3 | |
| 2158060 | 24 SHAFT-SUN GEAR | 3 | |
| 2159546 | 25 CARRIER | 1 | |
| 2168120 | 26 HUB | 1 | |
| 2168121 | 27 HUB | 1 | |
| 2168122 | 28 HOUSING | 1 | |
| 2496320 | 29 KIT-SEAL | 1 | |
| 1570739 | SEAL-LIP TYPE | 1 | |
| 1687010 | SEAL-LIP TYPE | 1 | |
| 1990669 | 30 PLUG (THRUST) | 1 | |
| 5H4909 | 31 SEAL-O-RING | 1 | |
| 3045673 | 32 WASHER-THRUST (40X60X1.5-MM THK) | 3 | |
| 4D2297 | 33 SEAL-O-RING | 2 |
