System And Components
468-0687 LINES GP-OIL COOLERS/N H221-UP
Group No: 468-0687
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 2 | |
| 1503050 | 2 CONNECTOR AS | 1 | |
| 6V7486 | CONNECTOR | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 2061531 | 3 SADDLE | 1 | |
| 2487591 | 4 VALVE GP-CHECK | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 3233309 | 5 CAP | 6 | |
| 4626729 | 6 HOSE AS | 1 | |
| 4666992 | 7 BRACKET AS | 1 | |
| 4667013 | 8 TUBE AS | 1 | |
| 1667015 | 9 SUPPORT | 1 | |
| 4680692 | 10 HOSE AS | 1 | |
| 4680693 | 11 TUBE AS | 1 | |
| 4680696 | 12 TUBE AS | 1 | |
| 4680698 | 13 TUBE AS | 1 | |
| 4680700 | 14 CLAMP | 3 | |
| 4683866 | 15 HOSE AS | 1 | |
| 4804822 | 16 PLATE | 3 | |
| 4863750 | 17 HOSE (15-IN) | 1 | |
| 1114013 | 18 GROMMET | 1 | |
| 1488327 | 19 CONNECTOR AS | 4 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488342 | 20 CONNECTOR AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8632 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488357 | 21 ELBOW AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9008 | ELBOW | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1504033 | 22 ADAPTER AS | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 6V9846 | TEE | 1 | |
| 2899139 | 24 CLAMP-BAND | 2 | |
| 3737622 | 25 CLAMP-BAND | 1 | |
| 1467453 | 26 HOSE | 1 | |
| 4804857 | 27 HOSE | 1 | |
| 6V9746 | 28 SEAL-O-RING | 1 | |
| 4L3641 | 29 CLIP | 1 | |
| 8T4121 | 30 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4137 | 31 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4196 | 32 BOLT (M10X1.5X35-MM) | 3 | |
| 8T4224 | 33 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T7547 | 34 BOLT (M8X1.25X30-MM) | 2 | |
| 7X7958 | 35 CLAMP-HOSE | 4 |
