System And Components
466-4880 TANK & MTG GP-DEFS/N H221-UP
Group No: 466-4880
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3192305 | 1 CAM-LATCH | 1 | |
| 3642475 | 2 SEAL-STRIP | 2 | |
| 3896955 | 3 LOCK AS | 1 | |
| 4243400 | 4 HINGE AS | 1 | |
| 4516794 | 5 SEAL | 1 | |
| 4567847 | 6 STRAP AS | 2 | |
| 4660637 | 7 BOX AS | 1 | |
| 1599539 | NUT-WELD (M6X1-THD) | 4 | |
| 1599540 | NUT-WELD (M8X1.25-THD) | 4 | |
| 4660643 | 8 PLATE | 1 | |
| 4660644 | 9 PLATE | 1 | |
| 4660645 | 10 GUARD AS-SPILL | 1 | |
| 4687295 | 11 TANK GP-DIESEL EXHAUST FLUID | 1 | |
| 4868731 | 12 HOSE | 1 | |
| 3445673 | 13 NUT (M6X1-THD) | 2 | |
| 3445674 | 14 NUT (M8X1.25-THD) | 4 | |
| 7Y6190 | 15 BOLT (M8X1.25X20-MM) | 4 | |
| 8T4205 | 16 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 8T4224 | 17 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 8T4908 | 18 BOLT (M8X1.25X25-MM) | 4 | |
| 9X2043 | 19 SCREW-TRUSS HEAD (M6X1X14-MM) | 4 | |
| 9X2044 | 20 SCREW-TRUSS HEAD (M6X1X16-MM) | 2 | |
| 6V2495 | 21 SEAL (0.7-M) | ||
| 3988225 | 22 COVER | 1 |
