466-0742 LIGHTING GP-ROADINGS/N H221-UP

Group No: 466-0742

Part Number	Part Name	Qty
3S2093	1 STRAP-CABLE	1
1649425	2 HORN AS (12-VOLT, LOW TONE)	1
1950189	3 LAMP GP-HEAD & SIGNAL (12V)	1
1950190	4 LAMP GP-HEAD & SIGNAL (12V)	1
2624726	5 LAMP GP-STOP & TAIL (12-VOLT)	2
9W3326	LAMP (12-VOLT, 21-WATT)	2
1087605	LAMP (12-VOLT, 5-WATT)	1
3447953	LENS	1
2624727	6 LAMP GP-ROADING (12-VOLT)	1
9W3326	LAMP (12-VOLT, 21-WATT)	1
3447954	LENS	1
2624728	7 LAMP GP-BACKUP (12-VOLT)	1
9W3326	LAMP (12-VOLT, 21-WATT)	1
3447955	LENS	1
3962497	8 HARNESS AS-LIGHTING (REVERSE LIGHT)	1
3962500	9 HARNESS AS-LIGHTING (FOG LIGHT, REAR)	1
4302637	10 PLATE	1
4319837	11 PLATE	1
5026725	12 BRACKET AS (RH)	1
5026726	13 BRACKET AS (LH)	1
4374828	14 PLATE AS	1
8T3490	NUT-WELD (M10X1.5-THD)	1
4391618	15 HARNESS AS-FRONT (HORN)	1
1028802	KIT-RECEPTACLE (2-PIN)	1
8T8730	SOCKET-CONNECTOR (16-GA TO 20-GA)	2
9W0852	PIN-CONNECTOR (14-GA TO 16-GA)	2
2458026	PLUG AS-CONNECTOR (2-PIN)	1
2Y5429	16 GROMMET	1
4P7581	17 CLIP (LADDER)	1
5C2890	18 NUT (M6X1-THD)	8
5C4116	19 HOSE AS	4
7X2537	20 BOLT (M8X1.25X35-MM)	2
8S7583	21 GROMMET	2
8T4121	22 WASHER-HARD (11X21X2.5-MM THK)	1
8T4137	23 BOLT (M10X1.5X20-MM)	1
8T4189	24 BOLT (M8X1.25X20-MM)	4
8T4205	25 WASHER-HARD (7.2X14.5X2-MM THK)	8
8T4224	26 WASHER-HARD (8.8X16X2-MM THK)	6
8T4908	27 BOLT (M8X1.25X25-MM)	4
