System And Components
499-2185 CLUTCH GP-TRANSMISSIONS/N H221-UP
Group No: 499-2185
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7T9342 | 1 CONE-BEARING | 2 | |
| 7T9343 | 2 CUP-BEARING | 2 | |
| 4602629 | 3 SHAFT-CLUTCH | 1 | |
| 1838620 | 4 BALL BEARING | 2 | |
| 4602631 | 5 HOUSING-CLUTCH | 1 | |
| 1613910 | 6 RING-RETAINING | 1 | |
| 1096495 | 7 RING-RETAINING | 1 | |
| 4602632 | 8 DISC | 1 | |
| 4602633 | 9 DISC-FRICTION | 9 | |
| 4602634 | 10 DISC-CLUTCH | 9 | |
| 4602635 | 11 SPRING | 4 | |
| 3888364 | 12 BEARING AS-TAPERED ROLLER | 1 | |
| 6Y2736 | CONE-BEARING | 1 | |
| 6Y2737 | CUP-BEARING | 1 | |
| 4602637 | 13 COVER | 1 | |
| 4992183 | 14 HOUSING-CLUTCH | 1 | |
| 4602639 | 15 PISTON | 1 | |
| 1012862 | 16 DOWEL | 1 | |
| 4602640 | 17 DISC | 1 | |
| 5P8428 | 18 SEAL-O-RING | 1 | |
| 8T9527 | 19 SEAL-O-RING | 1 | |
| 4602641 | 20 SPRING | 2 | |
| 5171789 | 21 SEAL-O-RING | 2 | |
| 8C3076 | 22 SEAL-O-RING | 4 | |
| 2748041 | 23 VALVE GP-SOLENOID (12-VOLT)(PILOT SHUTOFF) | 1 | |
| 2508330 | KIT-SEAL (SOLENOID VALVE) | 1 | |
| 1533568 | 24 BOLT-SOCKET HEAD (M5X0.8X10-MM) | 2 | |
| 6V3822 | 25 BOLT (M10X1.5X35-MM) | 3 | |
| 2416170 | 26 PLUG | 1 | |
| 4753800 | 27 SWITCH AS (PRESSURE) | 1 | |
| 4649489 | 28 PLUG | 1 | |
| 4649490 | 29 PLUG | 1 | |
| 2609153 | 30 PLUG | 4 | |
| 3853599 | 31 PLUG AS | 1 | |
| 1800875 | WASHER (22.8X27.1X1.4-MM THK) | 1 | |
| 2287101 | 32 SEAL-O-RING | 1 | |
| 5W9522 | 33 WASHER | 1 | |
| 1879630 | 34 SEAL-O-RING | 2 |
