System And Components
453-2383 DRIVE GP-HYDROSTATICS/N H221-UP
Group No: 453-2383
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7T5609 | 1 BOLT | 5 | |
| 8T4121 | 2 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 4532384 | 3 COVER | 1 | |
| 1367808 | 4 BEARING AS-TAPERED ROLLER | 2 | |
| 4532385 | 5 HOUSING | 1 | |
| 4532386 | 6 SHAFT-INPUT | 1 | |
| 1513568 | 7 BEARING | 1 | |
| 4532387 | 8 COVER-MOTOR | 1 | |
| 5F5434 | 9 VALVE AS-VENT (TRANSMISSION) | 1 | |
| 7T5410 | 10 LOCKWASHER | 4 | |
| 9R6816 | 11 STUD | 4 | |
| 5P5397 | 12 SEAL-O-RING | 1 | |
| 4532388 | 13 FLANGE | 1 | |
| 6V3668 | 14 BOLT (M12X1.75X30-MM) | 4 | |
| 7T3427 | 15 WASHER | 4 | |
| 4532389 | 16 COVER | 1 | |
| 1603937 | 17 SEAL (55-MM THK) | 1 | |
| 4532390 | 18 SHIM (1.5-MM THK) | 2 | |
| 4532391 | 19 SPACER (50X60.3X7-MM THK) | 1 | |
| 7T1608 | 20 PLUG | 2 | |
| 7T1609 | 21 PLUG-MAGNETIC (TRANSFER GEAR) | 1 | |
| 4532392 | 22 COVER | 1 | |
| 7T3432 | 23 SEAL-RING | 1 | |
| 8T1158 | 24 BOLT-SOCKET HEAD (M8X1.25X20-MM) | 4 | |
| 8T0338 | 25 BOLT-SOCKET HEAD (M8X1.25X45-MM) | 4 | |
| 4532393 | 26 SHAFT-OUTPUT | 1 | |
| 3907668 | 27 NUT-HEX FLANGE (M20X1.5-THD) | 1 | |
| 8I4438 | 28 NUT (M14X1-THD) | 4 | |
| 4532394 | 29 KIT-SHIM | 2 | |
| 4532396 | 30 GEAR-INPUT | 1 | |
| 4532397 | 31 GEAR-OUTPUT | 1 | |
| 4532395 | 32 SHIM (2-MM THK) | 1 | |
| 6V3822 | 33 BOLT (M10X1.5X35-MM) | 8 |
