System And Components
463-8000 DOOR GP-HOOD -RHS/N H221-UP
Group No: 463-8000
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1782593 | 1 BUMPER | 2 | |
| 9X2299 | 2 LATCH AS | 1 | |
| 3192305 | 3 CAM-LATCH | 1 | |
| 3896955 | 4 LOCK AS | 1 | |
| 3988225 | 5 COVER | 1 | |
| 4183616 | 6 PLATE AS | 1 | |
| 1599540 | NUT-WELD (M8X1.25-THD) | 1 | |
| 1599541 | NUT-WELD (M10X1.5-THD) | 1 | |
| 4270093 | 7 PLATE AS | 1 | |
| 4330205 | 8 HINGE AS | 1 | |
| 4330253 | 9 PLATE | 1 | |
| 4637995 | 10 HINGE | 2 | |
| 4640294 | 11 DOOR AS-ACCESS | 1 | |
| 4688261 | 12 PLATE AS | 1 | |
| 4688262 | 13 PLATE | 1 | |
| 4804836 | 14 PLATE AS | 1 | |
| 5052375 | 15 CAP | 2 | |
| 2986020 | 16 BOLT-SOCKET HEAD (M8X1.25X60-MM) | 2 | |
| 3293356 | 17 NUT (M12X1.75-THD) | 4 | |
| 3445673 | 18 NUT (M6X1-THD) | 6 | |
| 3445674 | 19 NUT (M8X1.25-THD) | 6 | |
| 7X0579 | 20 WASHER-HARD (8.8X25.5X2-MM THK) | 2 | |
| 7X0618 | 21 WASHER-HARD (13.5X40X5-MM THK) | 4 | |
| 7X7729 | 22 WASHER (11X25X3-MM THK) | 6 | |
| 8T4121 | 23 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4136 | 24 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4195 | 25 BOLT (M10X1.5X30-MM) | 4 | |
| 8T4196 | 26 BOLT (M10X1.5X35-MM) | 8 | |
| 8T4205 | 27 WASHER-HARD (7.2X14.5X2-MM THK) | 6 | |
| 8T4224 | 28 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9X2042 | 29 SCREW-TRUSS HEAD (M6X1X12-MM) | 4 | |
| 9X2045 | 30 SCREW-TRUSS HEAD (M6X1X20-MM) | 4 | |
| 3736044 | 31 SEAL (66-CM) | ||
| 4759326 | 32 INSULATION | 1 |
