System And Components
557-1132 KIT-FOURTH FUNCTION HYDRAULICS/N H221-UP
Group No: 557-1132
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1488315 | 1 CONNECTOR AS | 4 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8642 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 7K1181 | 2 STRAP-CABLE | 2 | |
| 9V6589 | 3 CLAMP-DOUBLE | 8 | |
| 1028705 | 4 PLATE (TOP) | 4 | |
| 0341432 | 5 STRAP-CABLE | 2 | |
| 2681643 | 6 CONNECTOR AS | 4 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 2681642 | CONNECTOR | 1 | |
| 2909636 | 7 PLATE AS | 1 | |
| 1599539 | NUT-WELD (M6X1-THD) | 4 | |
| 3988839 | 8 FILM-INSTRUCTION (LOADER CONTROL) | 1 | |
| 4369757 | 9 PLATE | 4 | |
| 4535198 | 10 CLAMP | 4 | |
| 4535199 | 11 CLAMP | 4 | |
| 4790627 | 12 VALVE GP-BANK 4 (HIGH FLOW) | 1 | |
| 5095941 | 13 BRACKET (RH) | 1 | |
| 5095942 | 14 BRACKET (LH) | 1 | |
| 1536256 | 15 ELBOW AS | 4 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 8C7563 | ELBOW | 1 | |
| 1552255 | 16 KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 1783620 | 17 STRAP-DUAL CLAMP | 2 | |
| 2060452 | 18 PLATE | 4 | |
| 3445674 | 19 NUT (M8X1.25-THD) | 4 | |
| 3994364 | 20 HOSE AS | 4 | |
| 3E8020 | 21 SCREW-TRUSS HEAD (M6X1X25-MM) | 2 | |
| 4233072 | 22 CONTROL GP-JOYSTICK | 1 | |
| 1519275 | KIT-RECEPTACLE (6-PIN) | 1 | |
| 1743091 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 1753358 | PLUG AS | 1 | |
| 6V9170 | 23 NUT-BULKHEAD (1-14-THD) | 4 | |
| 8T4121 | 24 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4137 | 25 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4224 | 26 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T6870 | 27 BOLT (M8X1.25X70-MM) | 12 | |
| 8T8737 | 28 PLUG-SEAL | 12 |
