System And Components
486-3772 LINES GP-AUXILIARY HYDRAULICS/N H221-UP
Group No: 486-3772
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9V6589 | 1 CLAMP-DOUBLE | 8 | |
| 1028705 | 2 PLATE (TOP) | 4 | |
| 2060452 | 3 PLATE | 4 | |
| 2681643 | 4 CONNECTOR AS | 4 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 2681642 | CONNECTOR | 1 | |
| 3994364 | 5 HOSE AS | 4 | |
| 4369757 | 6 PLATE | 4 | |
| 4535198 | 7 CLAMP | 4 | |
| 4535199 | 8 CLAMP | 4 | |
| 5095941 | 9 BRACKET (RH) | 1 | |
| 5095942 | 10 BRACKET (LH) | 1 | |
| 1488315 | 11 CONNECTOR AS | 4 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8642 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1536256 | 12 ELBOW AS | 4 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 8C7563 | ELBOW | 1 | |
| 1783620 | 13 STRAP-DUAL CLAMP | 2 | |
| 3445674 | 14 NUT (M8X1.25-THD) | 4 | |
| 6V9170 | 15 NUT-BULKHEAD (1-14-THD) | 4 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4137 | 17 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4224 | 18 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T6870 | 19 BOLT (M8X1.25X70-MM) | 12 |
