469-7412 LINES GP-COUPLERS/N H221-UP

Group No: 469-7412

Part Number	Part Name	Qty
7K1181	1 STRAP-CABLE	2
1028705	2 PLATE (TOP)	4
1234750	3 VALVE AS-CHECK (COUPLER, REAR)	1
3J1907	SEAL-O-RING	1
6V8397	SEAL-O-RING (ORFS)	1
2060452	4 PLATE	4
2062423	5 SADDLE-MOUNTING	1
4193480	6 HOSE AS	1
4193486	7 HOSE AS	1
4193517	8 BRACKET	1
4254978	9 HOSE AS	1
4372886	10 MANIFOLD GP-CONTROL (COUPLER LINES)	1
4578728	11 CLAMP-DOUBLE	8
4697415	12 HOSE AS	1
4697417	13 HOSE AS	1
4697418	14 HOSE AS	1
0392281	15 SPACER (9X16X25-MM THK)	2
1488325	16 CONNECTOR AS	2
3J1907	SEAL-O-RING	1
4J5477	SEAL-O-RING	1
6V8641	CONNECTOR	1
1488336	17 CONNECTOR AS	2
3J1907	SEAL-O-RING	1
6V8397	SEAL-O-RING	1
6V8636	CONNECTOR	1
1488378	18 ELBOW AS	2
3J1907	SEAL-O-RING	1
6V8397	SEAL-O-RING	1
6V8724	ELBOW	1
1488433	19 TEE AS	1
6V8397	SEAL-O-RING	2
6V9836	TEE-SWIVEL	1
1488439	20 TEE AS	1
3J1907	SEAL-O-RING	1
6V8397	SEAL-O-RING	2
6V8774	TEE	1
1495452	21 UNION AS (STRAIGHT)	2
6V8397	SEAL-O-RING	2
6V8994	UNION (STRAIGHT)	1
1783620	22 STRAP-DUAL CLAMP	1
1809933	23 ADAPTER AS	1
3J7354	SEAL-O-RING	1
1359941	ADAPTER	1
1G9959	24 CLAMP	12
4338930	25 HOSE AS	1
4338931	26 HOSE AS	1
6V9168	27 NUT (11/16-16-THD)(BULKHEAD)	2
7V5628	28 PLATE (TOP)(TOP)	6
7X0818	29 BOLT (M8X1.25X45-MM)(HEX HEAD)	2
7X2539	30 BOLT (M8X1.25X110-MM)(HEX HEAD)	4
8C8451	31 BOLT (M6X1X40-MM)(HEX HEAD)	8
8T4136	32 BOLT (M10X1.5X25-MM)(HEX HEAD)	2
8T4222	33 WASHER-PLATED (11X32X2.5-MM THK)	2
8T4224	34 WASHER-HARD (8.8X16X2-MM THK)	2
7X2534	35 BOLT (M6X1X50-MM)(HEX HEAD)	4
