System And Components
469-7430 LINES GP-LIFT & TILT -BOOM CYLINDERS/N H221-UP
Group No: 469-7430
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 2 | |
| 1028705 | 2 PLATE (TOP) | 4 | |
| 1978940 | 3 CONNECTOR AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 8T1576 | CONNECTOR | 1 | |
| 2060452 | 4 PLATE | 4 | |
| 2062423 | 5 SADDLE-MOUNTING | 1 | |
| 3233309 | 6 CAP | 6 | |
| 3369715 | 7 BLOCK | 3 | |
| 3901434 | 8 HOSE AS | 1 | |
| 3901435 | 9 HOSE AS | 1 | |
| 3901437 | 10 HOSE AS | 1 | |
| 4193519 | 11 HOSE AS | 1 | |
| 4193562 | 12 HOSE AS | 2 | |
| 4270034 | 13 TUBE AS | 1 | |
| 4302649 | 14 TUBE AS | 2 | |
| 1218004 | 15 CLAMP | 8 | |
| 1488315 | 16 CONNECTOR AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8642 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488388 | 17 ELBOW AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8629 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488390 | 18 ELBOW AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8626 | ELBOW | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488392 | 19 ELBOW AS | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 6V9853 | ELBOW | 1 | |
| 1488446 | 20 TEE AS-SWIVEL | 2 | |
| 6V9838 | TEE-SWIVEL | 1 | |
| 7J9108 | SEAL-O-RING | 2 | |
| 1783620 | 21 STRAP-DUAL CLAMP | 3 | |
| 5P0599 | 22 CLAMP-BAND | 6 | |
| 6V8398 | 23 SEAL-O-RING | 2 | |
| 7J9108 | 24 SEAL-O-RING | 4 | |
| 8T6869 | 25 BOLT (M8X1.25X60-MM) | 4 | |
| 9R0982 | 26 BLOCK | 2 | |
| 9R2053 | 27 BLOCK | 1 |
