System And Components
462-7080 LINES GP-PILOTS/N H221-UP
Group No: 462-7080
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 2 | |
| 1028703 | 2 PLATE-COVER | 1 | |
| 1490686 | 3 ACCUMULATOR GP-HYDRAULIC (CHARGED) | 1 | |
| 2062423 | 4 SADDLE-MOUNTING | 1 | |
| 2965749 | 5 ELBOW AS | 1 | |
| 4J5477 | SEAL-O-RING | 2 | |
| 6V8986 | ELBOW | 1 | |
| 3142403 | 6 VALVE AS-CHECK (IMPLEMENT) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 4465204 | 7 CLAMP | 2 | |
| 4465205 | 8 PLATE | 1 | |
| 4681140 | 9 HOSE AS | 1 | |
| 4683366 | 10 HOSE AS | 1 | |
| 4683368 | 11 HOSE AS | 1 | |
| 4683381 | 12 HOSE AS | 1 | |
| 4688556 | 13 HOSE AS | 1 | |
| 4699188 | 14 BRACKET AS | 1 | |
| 4706178 | 15 HOSE AS | 1 | |
| 4713053 | 16 BRACKET AS | 1 | |
| 4790634 | 17 MANIFOLD GP-CONTROL | 1 | |
| 1488336 | 18 CONNECTOR AS | 5 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488366 | 19 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8987 | ELBOW | 1 | |
| 1488378 | 20 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1645567 | 21 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1783620 | 22 STRAP-DUAL CLAMP | 3 | |
| 1974103 | 23 CLAMP-HALF | 2 | |
| 2P1279 | 24 LOCKNUT (9/16-18-THD) | 1 | |
| 3K0360 | 25 SEAL-O-RING | 1 | |
| 6V0852 | 26 CAP-DUST | 1 | |
| 6V9168 | 27 NUT (11/16-16-THD) | 1 | |
| 7X2535 | 28 BOLT (M6X1X60-MM) | 2 | |
| 7X2537 | 29 BOLT (M8X1.25X35-MM) | 1 | |
| 8T4121 | 30 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4178 | 31 BOLT (M10X1.5X90-MM) | 2 | |
| 8T4182 | 32 BOLT (M10X1.5X45-MM) | 2 | |
| 8T4224 | 33 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T6912 | 34 BOLT (M8X1.25X50-MM) | 2 |
