System And Components
469-7420 LINES GP-RIDE CONTROLS/N H221-UP
Group No: 469-7420
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 2 | |
| 1028705 | 2 PLATE (TOP) | 4 | |
| 1978940 | 3 CONNECTOR AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 8T1576 | CONNECTOR | 1 | |
| 2060452 | 4 PLATE | 4 | |
| 2062423 | 5 SADDLE-MOUNTING | 1 | |
| 2762334 | 6 FILM-WARNING (HIGH PRESS CYLINDER, READ OMM) | 2 | |
| 3233309 | 7 CAP | 6 | |
| 3369715 | 8 BLOCK | 3 | |
| 3901434 | 9 HOSE AS | 1 | |
| 3901435 | 10 HOSE AS | 1 | |
| 3901437 | 11 HOSE AS | 1 | |
| 3901438 | 12 HOSE AS | 1 | |
| 3996480 | 13 HOSE AS | 1 | |
| 3996481 | 14 HOSE AS | 1 | |
| 4193522 | 15 HOSE AS | 1 | |
| 4193563 | 16 HOSE AS | 1 | |
| 4193564 | 17 HOSE AS | 1 | |
| 4270034 | 18 TUBE AS | 1 | |
| 4302649 | 19 TUBE AS | 2 | |
| 4372879 | 20 MANIFOLD GP-RIDE CONTROL (12-VOLT) | 1 | |
| 2384628 | COIL AS (12-VOLT) | 2 | |
| 4372898 | VALVE GP-SOLENOID (ACCUMULATOR) | 1 | |
| 4372899 | VALVE GP-SOLENOID (PRESSURE SWITCH) | 1 | |
| 3597231 | KIT-SEAL (RIDE CONTROL) | 1 | |
| 4561819 | 21 ACCUMULATOR GP-HYDRAULIC (CHARGED)(RIDE CONTROL) | 1 | |
| 4561820 | 22 ACCUMULATOR GP-HYDRAULIC (CHARGED)(RIDE CONTROL) | 1 | |
| 4601588 | 23 HOSE AS | 1 | |
| 4697423 | 24 HOSE AS | 1 | |
| 0919035 | 25 SPACER (11X25X20-MM THK) | 4 | |
| 1218004 | 26 CLAMP | 8 | |
| 1488315 | 27 CONNECTOR AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8642 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488340 | 28 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 1488345 | 29 CONNECTOR AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8638 | CONNECTOR | 1 | |
| 1488354 | 30 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9002 | ELBOW | 1 | |
| 1488364 | 31 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8625 | ELBOW | 1 | |
| 1488388 | 32 ELBOW AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8629 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488390 | 33 ELBOW AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8626 | ELBOW | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488407 | 34 PLUG AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 1488436 | 35 TEE AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V8775 | TEE-FACE SEAL | 1 | |
| 1488446 | 36 TEE AS-SWIVEL | 4 | |
| 6V9838 | TEE-SWIVEL | 1 | |
| 7J9108 | SEAL-O-RING | 2 | |
| 1488449 | 37 TEE AS-SWIVEL | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 6V9839 | TEE-SWIVEL | 1 | |
| 1783620 | 38 STRAP-DUAL CLAMP | 3 | |
| 2863018 | 39 CLIP (SLOT) | 4 | |
| 2863019 | 40 CLIP (TAB) | 4 | |
| 5P0599 | 41 CLAMP-BAND | 6 | |
| 6V8398 | 42 SEAL-O-RING | 2 | |
| 7J9108 | 43 SEAL-O-RING | 4 | |
| 8T3647 | 44 BOLT (M8X1.25X80-MM) | 2 | |
| 8T4121 | 45 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4185 | 46 BOLT (M10X1.5X50-MM) | 4 | |
| 8T4224 | 47 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T6869 | 48 BOLT (M8X1.25X60-MM) | 4 | |
| 9R0982 | 49 BLOCK | 2 | |
| 9R2053 | 50 BLOCK | 1 |
