System And Components
464-3866 LINES GP-STEERINGS/N H221-UP
Group No: 464-3866
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 1 | |
| 7K1181 | 2 STRAP-CABLE | 6 | |
| 9D7924 | 3 MOUNTING AS | 4 | |
| 9T3096 | 4 VALVE GP-CHECK (SECONDARY STEERING) | 1 | |
| 1028705 | 5 PLATE (TOP) | 1 | |
| 1117874 | 6 SEAL | 1 | |
| 9V6589 | 7 CLAMP-DOUBLE | 2 | |
| 1488424 | 8 TEE AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T8902 | ADAPTER-TEE | 1 | |
| 1488430 | 9 TEE AS | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 7X0873 | TEE | 1 | |
| 1696714 | 10 GASKET | 1 | |
| 1854026 | 11 VALVE GP-CHECK | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 2060452 | 12 PLATE | 1 | |
| 2062423 | 13 SADDLE-MOUNTING | 3 | |
| 2595487 | 14 PLATE | 1 | |
| 2815980 | 15 TEE AS | 1 | |
| 9X2541 | TEE-O-RING PORT | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 2877292 | 16 TEE AS | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1102218 | TEE-SWIVEL | 1 | |
| 3135104 | 17 SWITCH AS-PRESSURE (SECONDARY STEERING OIL) | 1 | |
| 3E3371 | WEDGE-RECEPTACLE LOCK (3-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 3 | |
| 9X1813 | SLEEVE (28-CM) | ||
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 3908147 | 18 HOSE AS | 1 | |
| 3908148 | 19 HOSE AS | 1 | |
| 3908149 | 20 HOSE AS | 1 | |
| 3908150 | 21 HOSE AS | 1 | |
| 3962575 | 22 MOTOR GP-ELEC HYD PUMP | 1 | |
| 3964891 | 23 VALVE GP-PRIORITY | 1 | |
| 4319831 | 24 PLATE AS | 1 | |
| 4319865 | 25 PLATE AS | 1 | |
| 4674646 | 26 HOSE AS | 1 | |
| 4674647 | 27 HOSE AS | 1 | |
| 4674710 | 28 HOSE AS | 1 | |
| 4674714 | 29 HOSE AS | 1 | |
| 4675004 | 30 HOSE AS | 1 | |
| 4683797 | 31 HOSE AS | 1 | |
| 4683809 | 32 HOSE AS | 1 | |
| 4703185 | 33 HOSE AS | 1 | |
| 1488307 | 34 ADAPTER AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 5P8874 | ADAPTER | 1 | |
| 1488315 | 35 CONNECTOR AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8642 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488324 | 36 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 6V9874 | CONNECTOR | 1 | |
| 1488326 | 37 CONNECTOR AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9872 | CONNECTOR | 1 | |
| 1488327 | 38 CONNECTOR AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488340 | 39 CONNECTOR AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 1488342 | 40 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8632 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488354 | 41 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9002 | ELBOW | 1 | |
| 1488361 | 42 ELBOW AS (90-DEG) | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9200 | ELBOW | 1 | |
| 1488364 | 43 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8625 | ELBOW | 1 | |
| 1488390 | 44 ELBOW AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8626 | ELBOW | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488444 | 45 TEE AS-SWIVEL | 2 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V9837 | TEE-SWIVEL | 1 | |
| 1504046 | 46 ADAPTER AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 5P1404 | ADAPTER | 1 | |
| 1504048 | 47 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8722 | ELBOW | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1536237 | 48 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9004 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1645567 | 49 COUPLER AS-QUICK DISCONNECT (MALE) | 2 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1783620 | 50 STRAP-DUAL CLAMP | 3 | |
| 1A2209 | 51 BOLT (3/8-24X1.25-IN) | 2 | |
| 3445674 | 52 NUT (M8X1.25-THD) | 9 | |
| 3445675 | 53 NUT (M10X1.5-THD) | 6 | |
| 3841628 | 54 WASHER-HARD (8.8X35X4-MM THK) | 4 | |
| 3J1907 | 55 SEAL-O-RING | 1 | |
| 3K0360 | 56 SEAL-O-RING | 1 | |
| 4230095 | 57 PUMP GP-GEAR | 1 | |
| 6V0852 | 58 CAP-DUST | 2 | |
| 6V8397 | 59 SEAL-O-RING | 1 | |
| 6V8398 | 60 SEAL-O-RING | 4 | |
| 7G3228 | 61 GROMMET | 1 | |
| 8T4121 | 62 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4137 | 63 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4185 | 64 BOLT (M10X1.5X50-MM) | 3 | |
| 8T4189 | 65 BOLT (M8X1.25X20-MM) | 2 | |
| 8T4222 | 66 WASHER-PLATED (11X32X2.5-MM THK) | 6 | |
| 8T4224 | 67 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 8T4896 | 68 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 8T6869 | 69 BOLT (M8X1.25X60-MM) | 1 | |
| 8T7329 | 70 BOLT (M8X1.25X55-MM) | 1 |
