System And Components
397-6071 CONTROL GP-BUCKETS/N H221-UP
Group No: 397-6071
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2924872 | 1 WASHER (66X100X0.35-MM THK) | 28 | |
| 3280722 | 2 PLATE | 4 | |
| 3751442 | 3 RING-RETAINING | 2 | |
| 3923010 | 4 PIN | 1 | |
| 3923011 | 5 PIN | 2 | |
| 3923012 | 6 PIN | 1 | |
| 3923013 | 7 PIN | 2 | |
| 3928632 | 8 PIN AS | 2 | |
| 3994554 | 9 PIN | 2 | |
| 3996568 | 10 PLATE AS | 2 | |
| 4193524 | 11 LEVER AS | 1 | |
| 4175825 | 11A BUSHING | 2 | |
| 4190477 | 11B BUSHING | 1 | |
| 5180073 | 12 PIN AS | 1 | |
| 5421541 | 13 ARM & BEARING AS | 1 | |
| 4175823 | 13A BUSHING | 2 | |
| 4175824 | 13B BUSHING | 2 | |
| 4175826 | 13C BUSHING | 2 | |
| 4302639 | 14 PLATE | 4 | |
| 4344385 | 15 PIN AS | 2 | |
| 1361122 | 16 SPACER (13.8X25X10-MM THK) | 2 | |
| 7X0618 | 17 WASHER-HARD (13.5X40X5-MM THK) | 5 | |
| 8T4139 | 18 BOLT (M12X1.75X30-MM) | 8 | |
| 8T4192 | 19 BOLT (M12X1.75X25-MM) | 3 | |
| 8T4223 | 20 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 8T4956 | 21 BOLT (M12X1.75X35-MM) | 10 |
