System And Components
398-8770 DOOR GP-CAB -LHS/N H221-UP
Group No: 398-8770
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1977499 | 1 BOLT (M4X0.7X25-MM) | 4 | |
| 2509308 | 2 CLIP | 2 | |
| 2521862 | 3 HANDLE AS-PULL | 1 | |
| 2521863 | 4 GASKET | 1 | |
| 2692890 | 5 CLEVIS | 1 | |
| 2692892 | 6 PIN | 1 | |
| 2692893 | 7 CLIP | 1 | |
| 2736182 | 8 GROMMET | 1 | |
| 5055609 | 9 SEAL-DOOR | 1 | |
| 2777590 | 10 COVER-DOOR | 1 | |
| 2784216 | 11 LEVER AS | 1 | |
| 2810525 | 12 GASKET | 1 | |
| 2924754 | 13 KNOB | 1 | |
| 3033003 | 14 WINDOW-SLIDING (LH) | 1 | |
| 3081192 | 15 SPACER (6.5X14X5.8-MM THK) | 1 | |
| 3081193 | 16 SPACER | 1 | |
| 3097530 | 17 LATCH AS-DOOR | 1 | |
| 4522677 | GASKET | 1 | |
| 4522678 | PLATE | 1 | |
| 4811013 | KNOB | 1 | |
| 4811018 | LATCH AS-DOOR | 1 | |
| 3113642 | 18 COVER | 1 | |
| 3988771 | 19 LOCK AS-DOOR | 1 | |
| 3988772 | 20 COVER-LOCK | 1 | |
| 3988782 | 21 ROD | 1 | |
| 3988783 | 22 DOOR AS-CAB | 1 | |
| 3988785 | 23 GLASS | 1 | |
| 1272170 | 24 SCREW-TRUSS HEAD (M8X1.25X20-MM) | 4 | |
| 3E4352 | 25 WASHER-HARD (8.8X20.5X2.5-MM THK) | 4 | |
| 6V7357 | 26 BOLT (M6X1X25-MM) | 3 | |
| 8T0328 | 27 WASHER-HARD (5.5X10X1-MM THK) | 4 | |
| 9X2045 | 28 SCREW-TRUSS HEAD (M6X1X20-MM) | 14 | |
| 9X8256 | 29 WASHER (6.6X12X2-MM THK) | 3 | |
| 5076134 | 30 PLATE | 2 |
