System And Components
500-3127 DIFFERENTIAL GPS/N H241-UP
Group No: 500-3127
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4981041 | 1 BEARING | 2 | |
| 4981036 | 2 CASE-DIFFERENTIAL | 1 | |
| 3D4072 | 3 BALL | 6 | |
| 4981023 | 4 PIN | 2 | |
| 1706705 | 5 BOLT-SOCKET HEAD (M8X1.25X12-MM) | 2 | |
| 8C8729 | 6 BOLT-SOCKET HEAD (M12X1.75X80-MM) | 16 | |
| 4981024 | 7 WASHER-THRUST | 4 | |
| 4981037 | 8 KIT-GEAR | 1 | |
| 4981022 | 9 WASHER-THRUST | 1 | |
| 8T3957 | 10 BOLT-SOCKET HEAD (M12X1.75X30-MM) | 4 | |
| 5A3604 | 11 BOLT-SOCKET HEAD (M8X1.25X25-MM) | 4 | |
| 5612576 | 12 KIT-BEVEL GEAR & PINION | 1 | |
| 3853605 | 13 BEARING | 2 | |
| 5003123 | 14 KIT-SHIM | 1 | |
| 5003124 | 15 KIT-SHIM | 1 | |
| 4981043 | 16 NUT-HEX FLANGE (M20X1.5-THD) | 1 | |
| 9C6250 | 17 SEAL-O-RING | 1 | |
| 4532363 | 18 KIT-FLANGE | 1 | |
| 3907680 | 19 NUT-RING (M40X1.5-THD) | 1 | |
| 5003122 | 20 SEAL-LIP TYPE | 1 | |
| 4907797 | 21 SEAL-O-RING | 1 | |
| 5267313 | 22 SEAL-O-RING | 1 | |
| 3853613 | 23 SPACER (42X50X20.8-MM THK) | 1 | |
| 5267327 | 24 PISTON | 1 | |
| 3853614 | 25 NUT-RING (M92X1.5-THD) | 2 | |
| 9S4185 | 27 PLUG (3/4-16-THD) | 1 | |
| 8I4428 | 29 WASHER | 1 | |
| 8I4427 | 30 SEAL-O-RING | 1 | |
| 4981021 | 31 WASHER-THRUST | 1 | |
| 1617630 | 32 KEY (SQUARE) | 1 | |
| 5273882 | 33 SPRING | 1 | |
| 4981015 | 34 SLEEVE-BEARING | 1 | |
| 0931731 | 35 RING-RETAINING | 1 | |
| 4907793 | 36 SCREW-ADJUSTING (M8X1X37-MM) | 2 | |
| 4981035 | KIT-DIFFERENTIAL | 1 |
