469-7410 LINES GP-COUPLERS/N H241-UP

Group No: 469-7410
Part NumberPart NameQty
7K11811 STRAP-CABLE2
10287052 PLATE (TOP)4
12347503 VALVE AS-CHECK1
6V8397SEAL-O-RING1
3J1907SEAL-O-RING1
20604524 PLATE4
20624235 SADDLE-MOUNTING1
41934806 HOSE AS1
41934867 HOSE AS1
41935178 BRACKET1
42549789 HOSE AS1
430262710 HOSE AS1
430262811 HOSE AS1
437288612 MANIFOLD GP-CONTROL1
457872813 CLAMP-DOUBLE8
469741514 HOSE AS1
469741715 HOSE AS1
469741816 HOSE AS1
039228117 SPACER (9X16X25-MM THK)2
108298918 BOLT (M8X1.25X130-MM)(HEX HEAD)4
148832519 CONNECTOR AS2
3J1907SEAL-O-RING1
4J5477SEAL-O-RING1
6V8641CONNECTOR1
148833620 CONNECTOR AS2
3J1907SEAL-O-RING1
6V8397SEAL-O-RING1
6V8636CONNECTOR1
148837821 ELBOW AS2
3J1907SEAL-O-RING1
6V8397SEAL-O-RING1
6V8724ELBOW1
148843322 TEE AS1
6V8397SEAL-O-RING2
6V9836TEE-SWIVEL1
148843923 TEE AS1
6V8397SEAL-O-RING2
3J1907SEAL-O-RING1
6V8774TEE1
149545224 UNION AS (STRAIGHT)2
6V8397SEAL-O-RING2
6V8994UNION (STRAIGHT)1
178362025 STRAP-DUAL CLAMP3
180993326 ADAPTER AS1
3J7354SEAL-O-RING1
1359941ADAPTER1
1G995927 CLAMP12
6V916828 NUT (11/16-16-THD)(BULKHEAD)2
7V562829 PLATE (TOP)(TOP)6
7X081830 BOLT (M8X1.25X45-MM)(HEX HEAD)2
7X253931 BOLT (M8X1.25X110-MM)(HEX HEAD)4
8C845132 BOLT (M6X1X40-MM)(HEX HEAD)8
8T413633 BOLT (M10X1.5X25-MM)(HEX HEAD)2
8T422234 WASHER-PLATED (11X32X2.5-MM THK)2
8T422435 WASHER-HARD (8.8X16X2-MM THK)2
7X253436 BOLT (M6X1X50-MM)(HEX HEAD)4
