System And Components
469-7440 LINES GP-AUXILIARY HYDRAULICS/N L241-UP
Group No: 469-7440
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2681643 | 1 CONNECTOR AS | 4 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 2681642 | CONNECTOR | 1 | |
| 3994364 | 2 HOSE AS | 2 | |
| 4369757 | 3 PLATE | 4 | |
| 5095941 | 4 BRACKET (RH) | 1 | |
| 5095942 | 5 BRACKET (LH) | 1 | |
| 4697431 | 6 CLAMP | 4 | |
| 4697432 | 7 CLAMP | 4 | |
| 4697433 | 8 CLAMP-HALF | 8 | |
| 4697434 | 9 HOSE AS | 2 | |
| 1488315 | 10 CONNECTOR AS | 4 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8642 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1536256 | 11 ELBOW AS | 2 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 8C7563 | ELBOW | 1 | |
| 2074499 | 12 PLATE-COVER | 4 | |
| 3445674 | 13 NUT (M8X1.25-THD) | 4 | |
| 6V9170 | 14 NUT-BULKHEAD (1-14-THD) | 4 | |
| 8T3647 | 15 BOLT (M8X1.25X80-MM) | 8 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4137 | 17 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4177 | 18 BOLT (M8X1.25X90-MM) | 4 | |
| 8T4224 | 19 WASHER-HARD (8.8X16X2-MM THK) | 12 |
