System And Components
504-1381 LINES GP-RETURNS/N HN81-UP
Group No: 504-1381
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1772215 | 1 STRAP-DUAL CLAMP | 17 | |
| 2006345 | 2 SADDLE-MOUNTING (DUAL SWIVEL) | 5 | |
| 2042281 | 3 STRAP-CABLE | 13 | |
| 7R7955 | 4 PLATE (SLOTTED) | 1 | |
| 7X0818 | 5 BOLT (M8X1.25X45-MM) | 2 | |
| 1964205 | 6 BOLT-STACKING (M6X1X44-MM) | 14 | |
| 1964206 | 7 BOLT-STACKING (M6X1X64-MM) | 2 | |
| 1G9960 | 8 CLAMP | 4 | |
| 5V6152 | 9 CLAMP | 10 | |
| 7R7938 | 10 CLAMP-PIPE | 2 | |
| 1019696 | 11 HOSE AS | 1 | |
| 1028705 | 12 PLATE (TOP) | 2 | |
| 1384572 | 13 COVER | 1 | |
| 2049815 | 14 ELBOW AS | 2 | |
| 6K6307 | SEAL-O-RING | 1 | |
| 8T0315 | SEAL-O-RING | 1 | |
| 8T1682 | ELBOW | 1 | |
| 2857206 | 15 CLAMP-HALF | 2 | |
| 3197931 | 16 HOSE AS | 1 | |
| 3467810 | 17 HOSE AS | 1 | |
| 3904483 | 18 HOSE AS | 1 | |
| 3906774 | 19 HOSE AS | 1 | |
| 3942542 | 20 HOSE AS | 1 | |
| 3942543 | 21 HOSE AS | 1 | |
| 4188100 | 22 HOSE AS | 1 | |
| 4188101 | 23 HOSE AS | 1 | |
| 4188102 | 24 HOSE AS | 1 | |
| 4188103 | 25 HOSE AS | 1 | |
| 4188106 | 26 HOSE AS | 1 | |
| 4188109 | 27 HOSE AS | 1 | |
| 4188704 | 28 HOSE AS | 1 | |
| 4188706 | 29 TUBE AS | 1 | |
| 4188707 | 30 HOSE AS | 1 | |
| 4194095 | 31 HOSE AS | 1 | |
| 4194096 | 32 HOSE AS | 1 | |
| 4578728 | 33 CLAMP-DOUBLE | 2 | |
| 4625019 | 34 HOSE AS | 1 | |
| 4910371 | 35 PLATE | 3 | |
| 5041382 | 36 TUBE AS | 1 | |
| 5041383 | 37 HOSE AS | 1 | |
| 5041385 | 38 HOSE AS | 1 | |
| 5041538 | 39 TUBE AS | 1 | |
| 5041541 | 40 HOSE AS | 1 | |
| 5070408 | 41 TUBE AS | 1 | |
| 5076489 | 42 HOSE AS | 1 | |
| 5134574 | 43 HOSE AS | 1 | |
| 5162901 | 44 TUBE AS | 1 | |
| 5227563 | 45 HOSE AS | 1 | |
| 1488433 | 46 TEE AS | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V9836 | TEE-SWIVEL | 1 | |
| 1488455 | 47 UNION AS | 1 | |
| 6V8997 | UNION | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 1488457 | 48 UNION AS (STRAIGHT) | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V8995 | UNION (STRAIGHT) | 1 | |
| 1654933 | 49 ELBOW AS | 1 | |
| 6V8990 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 1984775 | 50 WASHER-HARD (6.6X15X6-MM THK) | 1 | |
| 1S0994 | 51 CLIP (LOOP) | 2 | |
| 2093118 | 52 CLAMP-HALF | 2 | |
| 2P1293 | 53 LOCKNUT (1-3/16-12-THD) | 2 | |
| 5K9090 | 54 SEAL-O-RING | 1 | |
| 5P4115 | 55 WASHER-HARD (7.2X19X2-MM THK) | 7 | |
| 5P4116 | 56 WASHER-HARD (8.8X20.5X2-MM THK) | 1 | |
| 6V9169 | 57 NUT (13/16-16-THD) | 1 | |
| 6V9746 | 58 SEAL-O-RING | 4 | |
| 7C4354 | 59 CLIP | 1 | |
| 7R7908 | 60 CLAMP | 10 | |
| 7R7941 | 61 CLAMP | 2 | |
| 7R7951 | 62 PLATE | 3 | |
| 7R7954 | 63 PLATE | 7 | |
| 7V5626 | 64 CLAMP | 6 | |
| 7V5628 | 65 PLATE (TOP) | 5 | |
| 7V6089 | 66 CLAMP | 4 | |
| 7X2535 | 67 BOLT (M6X1X60-MM) | 7 | |
| 8C8451 | 68 BOLT (M6X1X40-MM) | 8 | |
| 8T0315 | 69 SEAL-O-RING | 3 | |
| 8T3844 | 70 BOLT (M6X1X70-MM) | 5 | |
| 8T4983 | 71 CLAMP-HOSE | 2 | |
| 8T6912 | 72 BOLT (M8X1.25X50-MM) | 1 | |
| 9X8256 | 73 WASHER (6.6X12X2-MM THK) | 4 | |
| 5P1423 | 74 HOSE (78-CM) | ||
| 9X2480 | 75 BOLT (M6X1X45-MM) | 2 |
