System And Components
451-4337 LINER GP-CABPART OF 451-4331 OPTION AR-CAB
Group No: 451-4337
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2629568 | 1 COVER-SPEAKER | 2 | |
| 3078161 | 2 ANCHOR | 17 | |
| 3078162 | 3 STUD-RATCHET | 17 | |
| 4558405 | 4 LINER AS-CAB | 1 | |
| 4558406 | 5 COVER | 1 | |
| 4558407 | 6 BRACKET AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 2 | |
| 4558409 | 7 LINER AS-CAB | 1 | |
| 4558410 | 8 COVER | 1 | |
| 4558411 | 9 COVER | 1 | |
| 4558413 | 10 COVER | 1 | |
| 4558414 | 11 PLATE | 1 | |
| 4563140 | 13 BRACKET AS | 1 | |
| 9X2032 | NUT-WELD (M4X0.7-THD) | 2 | |
| 1748131 | 14 SCREW-TRUSS HEAD (M4X0.7X12-MM) | 2 | |
| 5C2890 | 15 NUT (M6X1-THD) | 6 | |
| 5P4115 | 16 WASHER-HARD (7.2X19X2-MM THK) | 11 | |
| 9X2045 | 19 SCREW-TRUSS HEAD (M6X1X20-MM) | 13 | |
| 4674346 | 20 PLATE AS | 1 | |
| 8T4130 | STUD (M6X1X18-MM) | 2 | |
| 1728591 | 21 NUT-CLIP (M6X1-THD) | 3 | |
| 9X2043 | 22 SCREW-TRUSS HEAD (M6X1X14-MM) | 2 | |
| 4674341 | 23 COVER AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 2 |
