454-5874 BATTERY & WIRING GPS/N H221-UP

Group No: 454-5874

Part Number	Part Name	Qty
3S2093	1 STRAP-CABLE	1
7K1181	2 STRAP-CABLE	5
0815930	3 CABLE AS-CHASSIS	1
1S7251	TERMINAL-CABLE (00-GA, 1/2-IN SCREW)	2
2062423	4 SADDLE-MOUNTING	1
3739138	5 TERMINAL	1
4564973	6 CABLE AS	1
1S7252	TERMINAL-CABLE (00-GA, 3/8-IN SCREW)	1
5P0537	WASHER-HARD (7.2X14.5X2-MM THK)	1
1598050	CABLE (00-GA, BLACK)(39-CM)
5P9960	BOLT (1/4-20X0.75-IN)	1
3562508	TERMINAL-BATTERY (NEGATIVE)	1
4564975	7 CABLE AS	1
4759616	COVER-TERMINAL	1
8L8413	STRAP-CABLE (WHITE)	1
1S7252	TERMINAL-CABLE (00-GA, 3/8-IN SCREW)	1
5P0537	WASHER-HARD (7.2X14.5X2-MM THK)	1
5P9960	BOLT (1/4-20X0.75-IN)	1
8N0869	COVER-TERMINAL (RED)	1
1598049	CABLE (00-GA, RED)(111-CM)
2605151	TERMINAL-BATTERY	1
4564978	8 CABLE AS	1
5P5988	LOOM (0.8-M)
8C3056	CABLE (2-GA, RED)(123-CM)
5P3454	TERMINAL-RING (4-GA, 5/16-IN SCREW)	1
9G4336	TERMINAL-RING (4-GA, 3/8-IN SCREW)	1
4623712	9 BRACKET AS	1
4623729	10 CABLE AS	1
1598049	CABLE (00-GA, RED)(24-CM)
3150180	TERMINAL-RING (00-GA, 3/8-IN SCREW)	1
3519309	TUBE-HEAT SHRINK (32-MM DIA)(3-CM)
3772282	TERMINAL-RING	1
1355009	TUBE-HEAT SHRINK (32-MM DIA)(9-CM)
4808187	11 STRAP AS	1
1S7252	TERMINAL-CABLE (00-GA, 3/8-IN SCREW)	2
3457725	12 SCREW-TRUSS HEAD (M12X1.75X25-MM)	2
3523968	13 CLIP (LADDER)	3
4B4280	14 WASHER (13.5X27X2.5-MM THK)	1
9M8406	15 CLIP (LOOP)	2
5P4116	16 WASHER-HARD (8.8X20.5X2-MM THK)	1
5T6374	17 SPACER (11X20X40-MM THK)	1
5W2177	18 BOLT-SOCKET HEAD (M12X1.75X20-MM)	1
6V8801	19 NUT (3/8-16-THD)	2
7P1695	20 WASHER (10.5X19X3-MM THK)	2
7X2537	21 BOLT (M8X1.25X35-MM)	1
8F3590	22 LOCKWASHER	2
8N0869	23 COVER-TERMINAL (RED)	1
8T1887	24 CLIP (SLOT)	2
8T1888	25 CLIP (TAB)	2
8T4121	26 WASHER-HARD (11X21X2.5-MM THK)	6
8T4133	27 NUT (M10X1.5-THD)	2
8T4137	28 BOLT (M10X1.5X20-MM)	3
8T4172	29 BOLT (M10X1.5X80-MM)	1
8T4191	30 BOLT (M10X1.5X16-MM)	2
8T4223	31 WASHER-HARD (13.5X25.5X3-MM THK)	2
8T4896	32 WASHER-HARD (10.2X18.5X2.5-MM THK)	2
8X5489	33 SLEEVE	5
9B0453	34 LOCKWASHER	1
9X2044	35 SCREW-TRUSS HEAD (M6X1X16-MM)	2
