System And Components
Assembly
100%

507-6742 DIFFERENTIAL GPS/N H221-UP

Group No: 507-6742
Part NumberPart NameQty
5A36041 BOLT-SOCKET HEAD (M8X1.25X25-MM)4
17067052 BOLT-SOCKET HEAD (M8X1.25X12-MM)2
38536143 NUT-RING (M92X1.5-THD)2
49810414 BEARING2
17685185 BOLT (M12X1.25X35-MM)12
49000306 KIT-BEVEL GEAR1
39076827 WASHER (50X65X2-MM THK)2
49810528 GEAR-SIDE1
49810539 PINION4
500311810 WASHER-THRUST4
490780311 PIN4
507674412 RING-RETAINING4
095091913 RING-RETAINING4
490002314 GEAR-SIDE1
3D407215 BALL6
161763016 KEY (SQUARE)1
9C625017 SEAL-O-RING1
498104318 NUT-HEX FLANGE (M20X1.5-THD)1
8I442719 SEAL-O-RING1
8I442820 WASHER1
9S418521 PLUG (3/4-16-THD)1
490779323 SCREW-ADJUSTING (M8X1X37-MM)2
526731324 SEAL-O-RING1
490779725 SEAL-O-RING1
385360526 BEARING2
385360627 SHIM (0.2-MM THK)1
385361328 SPACER (42X50X20.8-MM THK)1
453235329 KIT-SHIM1
390768030 NUT-RING (M40X1.5-THD)1
390767931 SEAL-LIP1
5P388132 SEAL-O-RING1
390768533 SUPPORT1
8T027334 BOLT-SOCKET HEAD (M12X1.75X40-MM)8
453235635 KIT-PIN4
390767836 FLANGE1
526732837 PISTON1
500313438 BRAKE GP-CALIPER1
4907830KIT-DIFFERENTIAL1
