System And Components
544-3772 KICKOUT & POSITIONER GPS/N H221-UP
Group No: 544-3772
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4195 | 1 BOLT (M10X1.5X30-MM) | 2 | |
| 8T1889 | 2 CLIP (SLOT) | 2 | |
| 8T1890 | 3 CLIP (TAB) | 2 | |
| 8T4121 | 4 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4223 | 5 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4244 | 6 NUT (M12X1.75-THD) | 2 | |
| 8T4956 | 7 BOLT (M12X1.75X35-MM) | 2 | |
| 4863792 | 8 CLIP | 2 | |
| 4863793 | 9 CLAMP AS | 2 | |
| 4999513 | 10 PLATE | 4 | |
| 5429833 | 11 SENSOR AS-POSITION (RETURN TO DIG) | 1 | |
| 0965516 | 12 RING-RETAINING (EXTERNAL) | 1 | |
| 1658996 | 13 WASHER-THRUST (55.5X100.5X5-MM THK) | 1 | |
| 5G3676 | 14 GROMMET | 2 |
