System And Components
452-2608 CAB GPS/N H221-1707
Group No: 452-2608
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2595493 | 1 GLASS (RH) | 1 | |
| 2667068 | 2 GLASS (REAR) | 1 | |
| 2667069 | 3 GLASS | 1 | |
| 2667070 | 4 GLASS | 1 | |
| 2892136 | 5 PANEL GP-REAR | 1 | |
| 2615112 | PANEL AS-REAR | 1 | |
| 3988863 | 6 BRACKET AS | 2 | |
| 4381970 | 7 GLASS | 1 | |
| 4381971 | 8 GLASS | 1 | |
| 4522598 | 9 GLASS AS | 1 | |
| 5P5628 | TUBE (0.3-M) | ||
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 8T8737 | PLUG-SEAL | 1 | |
| 9W0852 | PIN-CONNECTOR (14-GA TO 16-GA) | 1 | |
| 1284178 | TERMINAL AS | 1 | |
| 2L8068 | TERMINAL-RING (10-GA TO 12-GA, 5/16-IN SCREW) | 1 | |
| 5P6006 | TUBE-HEAT SHRINK (9.52-MM DIA)(0.1-M) | ||
| 4564338 | 10 PLATE | 2 | |
| 3E8020 | 11 SCREW-TRUSS HEAD (M6X1X25-MM) | 6 | |
| 4522609 | 12 CAB AS | 1 | |
| 3988825 | HANDLE | 2 | |
| 2340095 | INSERT-THREADED (M6X1-THD) | 24 | |
| 9X2038 | 13 WASHER (7X19X2-MM THK) | 10 | |
| 9X2046 | 14 SCREW-TRUSS HEAD (M6X1X35-MM) | 4 |
