System And Components
190-5482 LINES GP-TORQUE CONV COOLERS/N AXR250-UP
Group No: 190-5482
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P3703 | 1 SEAL-RECTANGULAR | 2 | |
| 9V9116 | 2 SPACER (11.11X19.05X165-MM THK) | 1 | |
| 1180929 | 3 HOSE AS | 1 | |
| 1743352 | 4 HOSE AS | 1 | |
| 2351308 | 5 TUBE AS | 1 | |
| 2351309 | 6 TUBE AS | 1 | |
| 2351313 | 7 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 5K9090 | 8 SEAL-O-RING | 4 | |
| 5M7087 | 9 CLAMP-TUBE | 1 | |
| 6V8635 | 10 CONNECTOR | 1 | |
| 6V9008 | 11 ELBOW (90-DEG) | 1 | |
| 7M8485 | 12 SEAL-O-RING | 2 | |
| 8T4121 | 13 WASHER-HARD (11X21X2.5-MM THK) | 9 | |
| 8T4185 | 14 BOLT (M10X1.5X50-MM) | 1 | |
| 8T4189 | 15 BOLT (M8X1.25X20-MM) | 2 | |
| 8T4224 | 16 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T6466 | 17 BOLT (M10X1.5X60-MM) | 8 |
