118-1094 LINES GP-FRONTS/N DJD1-2977

Group No: 118-1094
Part NumberPart NameQty
6V98321 CAP (ORFS)2
11809922 TUBE AS1
11809933 TUBE AS1
13445314 HOSE AS2
11809965 BRACKET1
11809976 BRACKET1
2P12937 LOCKNUT (1-3/16-12-THD)2
8T41868 BOLT (M10X1.5X40-MM)2
5P74669 CLIP (SLOT)2
5P746710 CLIP (TAB)2
5P811211 GROMMET2
148833512 CONNECTOR AS2
5K9090SEAL-O-RING1
6V8635CONNECTOR1
7M8485SEAL-O-RING1
148845513 UNION AS2
6V8997UNION1
6V9746SEAL-O-RING2
6V974614 SEAL-O-RING2
8T413615 BOLT (M10X1.5X25-MM)8
7X772916 WASHER (11X25X3-MM THK)2
8T188917 CLIP (SLOT)4
8T189018 CLIP (TAB)4
8T412119 WASHER-HARD (11X21X2.5-MM THK)8
