System And Components
492-7185 FORK AR-GRAPPLES/N P5K1-UP
Group No: 492-7185
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2C9259 | 1 PLATE-IDENTIFICATION (CAT) | 2 | |
| 2V1195 | 2 SPACER-SPECIAL | 4 | |
| 3B8489 | 3 FITTING-GREASE (1/8-27 PTF) | 2 | |
| 1533742 | 4 TIP-WEAR | 2 | |
| 1533743 | 5 PIN-RETAINER | 4 | |
| 1533744 | 6 RING-RETAINING | 4 | |
| 2144285 | 7 PAD AS | 4 | |
| 2283369 | 8 FILM-WARNING (DO NOT OPERATE, READ OMM) | 1 | |
| 2533431 | 9 FILM-WARNING (CRUSH HAZARD, FORKS, READ OMM) | 1 | |
| 2706693 | 10 BUSHING | 2 | |
| 2765472 | 11 TUBE | 1 | |
| 4596638 | 13 CYLINDER GP-GRAPPLE | 2 | |
| 4607216 | 14 PIN AS | 2 | |
| 4607220 | 15 PIN AS | 2 | |
| 4607226 | 16 PIN AS | 2 | |
| 4607247 | 17 CLAMP AS | 1 | |
| 2663756 | 17A BUSHING | 4 | |
| 7K9209 | 17B SEAL-LIP TYPE | 4 | |
| 4607256 | 19 PLATE AS | 2 | |
| 4647494 | 20 FILM-WARNING (HAND CRUSH HAZARD, READ OMM) | 2 | |
| 4927189 | 22 VALVE & LINES GP | 1 | |
| 3445674 | 24 NUT (M8X1.25-THD) | 4 | |
| 6V7357 | 25 BOLT (M6X1X25-MM) | 3 | |
| 6V8337 | 26 BOLT-SOCKET HEAD (M8X1.25X35-MM) | 4 | |
| 8T4205 | 27 WASHER-HARD (7.2X14.5X2-MM THK) | 3 | |
| 8T4224 | 28 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T4956 | 29 BOLT (M12X1.75X35-MM) | 6 | |
| 8T5460 | 30 BOLT (M20X2.5X40-MM) | 16 |
