System And Components
136-7785 HEATER GP-CABS/N 6DS1-UP
Group No: 136-7785
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8F8151 | 1 VALVE-SHUTOFF | 1 | |
| 0039514 | 2 COUPLING-PIPE | 1 | |
| 0046683 | 3 FITTING | 1 | |
| 1082823 | 4 VALVE AS-SHUTOFF | 1 | |
| 5D1026 | 5 CLAMP-BAND | 4 | |
| 5P0767 | 6 HOSE (244CM) | ||
| 8T4178 | 7 BOLT (M10X1.5X90-MM) | 2 | |
| 1374142 | 8 HEATER GP-CAB | 1 | |
| 7X7729 | 9 WASHER (11X25X3-MM THK) | 5 | |
| 8T4136 | 10 BOLT (M10X1.5X25-MM) | 1 | |
| 1S0379 | 11 GASKET | 1 | |
| 1P5411 | 12 SLEEVE | 2 | |
| 8T4172 | 13 BOLT (M10X1.5X80-MM) | 2 | |
| 6D4244 | 14 CLIP (LOOP) | 6 | |
| 8T4121 | 15 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4195 | 16 BOLT (M10X1.5X30-MM) | 1 | |
| 8T4137 | 17 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4224 | 18 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 6P8855 | 19 SPACER-TUBE | 2 | |
| 6K6361 | 20 BUTTON-PLUG | 1 | |
| 8T4133 | 21 NUT (M10X1.5-THD) | 1 | |
| 1788008 | 22 HARNESS AS | 1 | |
| 1788010 | 23 WIRE AS | 1 | |
| 5P0767 | 24 HOSE (150-CM) |
