System And Components
289-9885 ARM GP-MATERIAL HANDLINGS/N KSA1-UP
Group No: 289-9885
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2926390 | 1 ARM AS | 1 | |
| 2C9259 | 1A PLATE-IDENTIFICATION (CAT) | 2 | |
| 1728335 | 1B CHAIN | 1 | |
| 1598035 | 2 FILM-WARNING (CRUSH HAZARD, STAY BACK) | 1 | |
| 1598036 | 3 FILM-WARNING (READ OMM) | 1 | |
| 2037643 | 4 CLEVIS | 1 | |
| 2037644 | 5 HOOK AS | 1 | |
| 2037730 | 5A KIT-LATCH | 1 | |
| 2222307 | 6 TUBE AS | 1 | |
| 1705707 | 7 LOCKPIN | 1 | |
| 6R1941 | 8 CONNECTOR | 1 | |
| 3W6116 | 9 PIN | 1 | |
| 5183003 | 10 FILM-WARNING (CRUSH HAZARD, READ OMM)(FOOT) | 1 |
