System And Components
488-9586 VALVE & LINES GP-LUBRICATIONS/N WGN183-UP
Group No: 488-9586
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1177629 | 1 TUBE AS | 2 | |
| 1177631 | 2 FITTING-COUPLING | 36 | |
| 2042281 | 3 STRAP-CABLE | 1 | |
| 4929946 | 4 VALVE GP-LUBE DISTRIBUTION (MAIN) | 1 | |
| 4929965 | 5 VALVE GP-LUBE DISTRIBUTION | 1 | |
| 2743833 | 6 FITTING | 28 | |
| 4930003 | 7 BRACKET AS | 1 | |
| 7T1099 | LINK | 1 | |
| 4930010 | 8 FITTING | 1 | |
| 4996958 | 9 FITTING-ADAPTER | 3 | |
| 3445673 | 10 NUT (M6X1-THD) | 2 | |
| 8T6974 | 11 BOLT (M6X1X80-MM) | 2 | |
| 9X8256 | 12 WASHER (6.6X12X2-MM THK) | 4 | |
| 1P0810 | 13 TAPE-ELECTRICAL | ||
| 1698323 | 14 HOSE (1.7-M EACH) | ||
| 1698323 | 14A HOSE (2.1-M EACH) | ||
| 1698323 | 14B HOSE (0.7-M EACH) | ||
| 1698323 | 14C HOSE (1.5-M EACH) | ||
| 1698323 | 14D HOSE (1.1-M EACH) | ||
| 1698323 | 14E HOSE (1.2-M) | ||
| 1698323 | 14F HOSE (0.3-M) | ||
| 5326171 | 15 CONNECTOR | 2 | |
| 4713702 | 16 SLEEVE | 2 | |
| 5W1636 | 17 NUT (M12X1.5-THD) | 2 |
