System And Components
310-9391 COUPLER GP-QUICKS/N N4A1-UP
Group No: 310-9391
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B8489 | 1 FITTING-GREASE (1/8-27 PTF) | 2 | |
| 8T4244 | 2 NUT (M12X1.75-THD) | 1 | |
| 1598036 | 3 FILM-WARNING (READ OMM) | 1 | |
| 1645847 | 4 HOSE AS | 4 | |
| 3111463 | 5 CYLINDER GP-COUPLER (HYDRAULIC) | 2 | |
| 3120220 | 6 HOSE AS | 2 | |
| 3124181 | 7 WEDGE AS | 2 | |
| 3235871 | 8 HOSE AS | 2 | |
| 3237089 | 9 FRAME AS | 1 | |
| 8T4223 | 10 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 3B4629 | 11 PIN-COTTER | 4 | |
| 3J7354 | 12 SEAL-O-RING | 6 | |
| 4J5477 | 13 SEAL-O-RING | 10 | |
| 6V8647 | 14 CONNECTOR | 6 | |
| 6W6211 | 15 PIN | 4 | |
| 7G2950 | 16 CLIP (SLOT) | 3 | |
| 7G2951 | 17 CLIP (TAB) | 3 | |
| 8T4139 | 18 BOLT (M12X1.75X30-MM) | 2 | |
| 8T4179 | 19 BOLT (M12X1.75X20-MM) | 1 | |
| 3156338 | KIT-PACKING (COUPLER CYLINDER)(QUICK COUPLER) | 1 |
