System And Components
8J5721 CYLINDER GROUP (Change V0)--(9K3169 N/S)--L.H.--4.50" Bore x 17.20" StrokePart of 8K6278 Top Clamp Arrangement listed on Page 261. AN ATTACHMENT
Group No: 8J5721
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8J5722 | 1 CYLINDER ASSEM. | 1 | |
| 8J5717 | 2 BEARING | 1 | |
| 3B4506 | 3 LOCKWASHER | 4 | |
| 5J4986 | 4 SEAL ASSEM. | 1 | |
| 2H3928 | 5 SEAL | 1 | |
| 1K7095 | 6 RING | 1 | |
| 2J3864 | 7 SHIM (.0478 in. thick) | 1 | |
| 2J3861 | 8 SHIM (.010 in. thick) | 6 | |
| 1K6981 | 9 SEAL | 1 | |
| 8J5724 | 10 ROD ASSEM. | 1 | |
| 8J5667 | 11 BEARING | 1 | |
| 3B1915 | 12 BOLT | 4 | |
| 2J3860 | 13 RETAINER | 1 | |
| 1D4608 | 14 BOLT | 4 | |
| 3B4512 | 15 LOCKWASHER | 4 | |
| 3F9609 | 16 PACKING | 1 | |
| 5J9989 | 17 HEAD | 1 | |
| 5J9986 | 18 PISTON | 1 | |
| 4J2620 | 19 RING | 1 | |
| 2J3950 | 20 NUT | 1 | |
| 3B8489 | 21 FITTING | 1 | |
| 5P0094 | 22 SEAL | 4 |
